NSN 5310-00-012-0622 MS35649282, MS35649-282 , MS3564982
Product Details | HEXAGON PLAIN NUT
5310-00-012-0622 A nut, flat on top and bottom having 6 flat sides. For items which have internal tapered or straight (parallel) pipe threads, specific electrical conduit size designation, and which when installed, provide a method of tightening to lock the connection, see LOCKNUT, ELECTRICAL CONDUIT. See also LOCKNUT, TUBE FITTING. For items having a thickness (or height) exceeding two times the width across the flats, use POST, ELECTRICAL-MECHANICAL EQUIPMENT. (When height or thickness and/or width across the flats is designated as a tolerance dimension, the maximum dimension will be used to determine compliance.
Part Alternates: MS35649282, MS35649-282 , MS3564982, MS35649-82, N016311F, BB8792, D11076287, D11076-28-7, D1107628A7, D11076-28A7, FFN836GR0UPCTYPE2STYLE1AND2, PC120622, XM236, 700095, 7374197, 7417863, 77903, 8X141, 92794, 110912, 1135273, 113-5273, 120622, 205017, 20501-7, 258000D3, 2580-00D3, 2584, 258-4, 32X3R, 34052S7, 4340, 4408, 5118362, 5118-3-62, 5310-00-012-0622, 00-012-0622, 5310000120622, 000120622
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-012-0622 | 01857 ( NUT, PLAIN, HEXAGON ) |
Drawings & Photos | NSN 5310-00-012-0622
Demand History | NSN 5310-00-012-0622
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS35649282 | 2024-03-78 | 20 | United States |
| MS35649282 | 2021-11-314 | 32 | United States |
| MS35649282 | 2020-03-66 | 33 | US |
| MS35649282 | 2019-08-232 | 128 | United States |
| 5310-00-012-0622 | 2018-12-354 | 4 | DIBBS-KIT |
| MS35649-282 | 2018-12-353 | 4 | |
| 4340 | 2015-12-349 | 5 | |
| 4340 | 2015-10-275 | 4 | |
| MS35649-282 | 2014-03-71 | 281 | United States |
| MS35649-282 | 2014-02-59 | 150 | United States |
| MS35649282 | 2010-04-118 | 520 | India |
| MS35649282 | 2008-11-323 | 10000 | US |
| MS35649282 | 2008-10-291 | 100 | China |
| MS35649282 | 2008-03-81 | 500 | United States |
Cross Reference | NSN 5310-00-012-0622
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 110912 | 73830 | GERSTENLAGER CO THE |
| 113-5273 | 11976 | CHICAGO PNEUMATIC TOOL CO |
| 113-5273 | 88687 | CHICAGO PNEUMATIC TOOL CO |
| 120622 | 12204 | DAIMLER CHRYSLER |
| 120622 | 16764 | GENERAL MOTORS CORP DELCO REMY DIV |
| 120622 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 120622 | 19204 | ARMY UNITED STATES DEPARTMENT OF THE |
| 120622 | 1LW55 | REMY, INC. |
| 120622 | 23705 | FRUEHAUF CORP |
| 120622 | 24617 | GENERAL MOTORS CORP |
| 120622 | 31007 | NAVISTAR INTL CORP |
| 120622 | 56442 | DIAMOND REO TRUCK CO |
| 120622 | 72582 | MTU AMERICA INC. |
| 120622 | 73331 | GENERAL MOTORS CORP FISHER GUIDE DIV |
| 120622 | D5589 | FEINMECHANISCHE WERKE MAINZ GMBH |
| 120622 | D9893 | LIEBHERR-AEROSPACE LINDENBERG GMBH |
| 20501-7 | 19315 | HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS FORMER BENDIX NAVIGATION AND |
| 20501-7 | 64547 | HONEYWELL INTERNATIONAL INC DBA HONEYWELL |
| 20501-7 | 83298 | ALLIED SIGNAL INC AEROSPACE EQUIPMENT SYSTEMS |
| 258-4 | 78189 | ITW SHAKEPROOF AUTOMOTIVE PRODUCTS |
| 2580-00D3 | 78189 | ITW SHAKEPROOF AUTOMOTIVE PRODUCTS |
| 32X3R | 83120 | PRESSED METALS OF AMERICA INC |
| 34052S7 | 23040 | FORD MOTOR CO FORD PARTS AND SERVICE DIV |
| 4340 | 27319 | HONEYWELL INC RESIDENTIAL DIV |
| 4408 | 24975 | PRESTOLITE ELECTRIC INCORPORATED |
| 4408 | 35510 | PRESTOLITE ELECTRIC INC |
| 5118-3-62 | 79466 | AESYS TECHNOLOGIES, L.L.C. DBA JACKSON & CHURCH HVAC GLOBAL |
| 5118-3-62 | 80372 | MARINE CORPS |
| 700095 | 55396 | SMITH OTIS A MFG CO |
| 7374197 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
| 7417863 | 19200 | US ARMY ARDEC RDECOM |
| 7417863 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
| 77903 | 57733 | STEWART-WARNER CORPORATION |
| 8X141 | 24975 | PRESTOLITE ELECTRIC INCORPORATED |
| 8X141 | 68505 | PRESTOLITE ELECTRIC INC |
| 92794 | 08645 | BRIGGS AND STRATTON CORP |
| BB8792 | 56442 | DIAMOND REO TRUCK CO |
| D11076-28-7 | 91340 | MET-PRO CORPORATION |
| D11076-28A7 | 91340 | MET-PRO CORPORATION |
| FFN836GR0UPCTYPE2STYLE1AND2 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| MS35649-82 | 81336 | CHIEF OF ENGINEERS DEPT OF ARMY |
| MS35649-82 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| N016311F | 56442 | DIAMOND REO TRUCK CO |
| PC120622 | C7432 | POWER COMPONENTS (DEUTSCHLAND) GMBH |
| XM236 | 09177 | AM MULTIGRAPHICS DIV OF AM INTL INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5310-00-012-0622
Technical Data | NSN 5310-00-012-0622
| Characteristic | Specifications |
|---|---|
| THREAD SERIES | UNC |
| NOMINAL THREAD SIZE | 0.164 INCHES |
| THREAD QUANTITY PER INCH | 32 |
| THREAD CLASS | 2B |
| THREAD DIRECTION | RIGHT-HAND |
| MATERIAL | STEEL OVERALL |
| SURFACE TREATMENT | CADMIUM OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416,TY 2,CL 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| HARDNESS RATING | NOT RATED |
| NUT STYLE | A12 HEXAGON |
| NUT HEIGHT | 0.117 INCHES MINIMUM AND 0.130 INCHES MAXIMUM |
| WIDTH ACROSS FLATS | 0.332 INCHES MINIMUM AND 0.344 INCHES MAXIMUM |
| BEARING SURFACE TYPE | FLAT |
| TEMP RATING | NOT RATED |
| MANUFACTURERS CODE | 81348 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | FFN836GR0UPCTYPE2STYLE1AND2 |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS35649-82 |
Restrictions/Controls & Freight Information | NSN 5310-00-012-0622
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
| Less than car load rating | U | 50 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 573 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
