Product Details | SHEET SPRING NUT
5310-00-550-3326 A nut formed from sheet spring material, usually steel, into varying flat, concave, bent or curved designs, having apertures with suitable boss or bosses usually on the upper side capable of securely gripping a mating threaded member. Excludes NUT (1), STAMPED.
Part Alternates: A619510Z1, A6195-10Z1, 5310-00-550-3326, 00-550-3326, 5310005503326, 005503326
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-550-3326 | 01865 ( NUT, SHEET SPRING ) |
Drawings & Photos | NSN 5310-00-550-3326
Demand History | NSN 5310-00-550-3326
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| A619510Z1 | 2012-05-136 | 12 | Canada |
| 5310-00-550-3326 | 2009-01-15 | 6 | Canada |
Cross Reference | NSN 5310-00-550-3326
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| A6195-10Z1 | 78553 | TINNERMAN PALNUT ENGINEERED PRODUCTS INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5310-00-550-3326
Related Products | NSN 5310-00-550-3326
Technical Data | NSN 5310-00-550-3326
| Characteristic | Specifications |
|---|---|
| MATING MEMBER DIAMETER ACCOMMODATED | 0.190 INCHES NOMINAL |
| MATERIAL | STEEL OVERALL |
| NUT STYLE | A165 SHEET SPRING |
| MATERIAL THICKNESS | 0.031 INCHES NOMINAL |
| NUT LENGTH | 0.950 INCHES MINIMUM AND 0.970 INCHES MAXIMUM |
| NUT WIDTH | 0.460 INCHES MINIMUM AND 0.480 INCHES MAXIMUM |
| NUT MOUNTING PROVISION | COUNTERSUNK HOLES |
| MOUNTING HOLE COUNTERSINK ANGLE | 97.0 DEGREES MINIMUM AND 103.0 DEGREES MAXIMUM |
| MOUNTING PROVISION LOCATION | NUT PROJECTION SIDE |
| MOUNTING HOLE ARRANGEMENT STYLE | F38 2 HOLES |
| MOUNTING HOLE DIAMETER | 0.682 INCHES MINIMUM AND 0.692 INCHES MAXIMUM |
| DISTANCE FROM APERTURE CENTER TO MOUNTING HOLE CENTER | 0.338 INCHES MINIMUM AND 0.348 INCHES MAXIMUM |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING HOLES ALONG LENGTH | 0.682 INCHES MINIMUM AND 0.692 INCHES MAXIMUM |
