NSN 5315-00-042-4819 MS276454A, MS27645-4A , AS276454A

Product Details | HEADLESS STRAIGHT PIN

5315-00-042-4819 A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.

Part Alternates: MS276454A, MS27645-4A , AS276454A, AS27645-4A , C697KS4A , SAE AS27645 , SAE AS27645-4A , SAEAS27645, SAEAS276454A, KS4AB100B000075K0000J , KS4AFS160, KSP4A , KSP4AFS464, KS4A, 10107325 , 1201578101, 1201578-101 , 2147249 , 2910003, 3103352 , 313352, 3KSP4A20 , 424819, 5315-00-042-4819, 00-042-4819, 5315000424819, 000424819
