NSN 5315-00-174-8667 MS17984616, MS17984-616, SLS6B16
Product Details | QUICK RELEASE PIN
5315-00-174-8667 A headed fastening device having a solid cylindrical or tubular body with retaining ball or pinlike detent(s). The detent(s) is/are positioned and actuated by means of a spring, elastomer or plunger. Plunger may be operated by thumb, cam or other means. May be furnished with a pull ring, pull and/or lock ring, attaching ring or hook.
Part Alternates: MS17984616, MS17984-616, SLS6B16, BLS6B16S, BLS6B16SM, LG6SB1600, LG6SB16M, 5315-00-174-8667, 00-174-8667, 5315001748667, 001748667
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 22-FEB-73 | 00-174-8667 | 08323 ( PIN, QUICK RELEASE ) |
Drawings & Photos | NSN 5315-00-174-8667
Cross Reference | NSN 5315-00-174-8667
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| BLC6B16S | 84256 | AVIBANK MFG., INC. |
| BLC6B16SM | 84256 | AVIBANK MFG., INC. |
| BLS6B16S | 84256 | AVIBANK MFG., INC. |
| BLS6B16SM | 84256 | AVIBANK MFG., INC. |
| LG6CB1600 | 62060 | SOUTHCO INC. |
| LG6CB1600 | 83014 | HARTWELL CORPORATION |
| LG6CB16M | 62060 | SOUTHCO INC. |
| LG6CB16M | 83014 | HARTWELL CORPORATION |
| LG6SB1600 | 62060 | SOUTHCO INC. |
| LG6SB1600 | 83014 | HARTWELL CORPORATION |
| LG6SB16M | 62060 | SOUTHCO INC. |
| LG6SB16M | 83014 | HARTWELL CORPORATION |
| MS17984-616 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| MS17984-616 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS17984C616 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| MS17984C616 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| NASM17984 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| NASM23460 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| SLC6AB16 | 16258 | SPACELOK INC. |
| SLS6B16 | 16258 | SPACELOK INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5315-00-174-8667
Technical Data | NSN 5315-00-174-8667
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 4130 SHANK STEEL COMP 4130 SPINDLE |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-T-6736 MIL SPEC SINGLE MATERIAL RESPONSE OR MIL-S-6758 MIL SPEC SINGLE MATERIAL RESPONSE SHANK MIL-T-6736 MIL SPEC SINGLE MATERIAL RESPONSE OR MIL-S-6758 MIL SPEC SINGLE MATERIAL RESPONSE SPINDLE |
| SURFACE TREATMENT | CADMIUM AND CHROMATE SHANK CADMIUM AND CHROMATE SPINDLE |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416,TY 2,CL 2 FED SPEC SINGLE TREATMENT RESPONSE SHANK QQ-P-416,TY 2,CL 2 FED SPEC SINGLE TREATMENT RESPONSE SPINDLE |
| HARDNESS RATING | 36.0 ROCKWELL C MINIMUM AND 40.0 ROCKWELL C MAXIMUM SHANK 36.0 ROCKWELL C MINIMUM AND 40.0 ROCKWELL C MAXIMUM SPINDLE |
| STYLE DESIGNATOR | Q243 BUTTON |
| SHANK DIAMETER | 0.3720 INCHES MINIMUM AND 0.3735 INCHES MAXIMUM |
| BUTTON HANDLE DIAMETER | 0.875 INCHES MINIMUM AND 1.135 INCHES MAXIMUM |
| GRIP LENGTH | 1.600 INCHES MINIMUM AND 1.620 INCHES MAXIMUM |
| SHOULDER TO HEAD END DISTANCE | 1.040 INCHES MAXIMUM |
| DETENT TO TAPERED END DISTANCE | 0.365 INCHES MAXIMUM |
| ACTUATION TYPE | PUSH |
| ACTUATION METHOD | PUSH BUTTON |
| DETENT QUANTITY | 2 |
| PIN ATTACHMENT TYPE | LINK OR RING |
| TEST DATA DOCUMENT | 81349-MIL-P-23199 SPECIFICATION |
Restrictions/Controls & Freight Information | NSN 5315-00-174-8667
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
