NSN 5315-00-241-2920 AN122705, AS122705, 20D12
Product Details | HEADLESS STRAIGHT PIN
5315-00-241-2920 A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.
Part Alternates: AN122705, AS122705, 20D12, 7577, 81466800, 814668-00, 9143M98P01, 5315-00-241-2920, 00-241-2920, 5315002412920, 002412920
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-241-2920 | 02390 ( PIN, STRAIGHT, HEADLESS ) |
Drawings & Photos | NSN 5315-00-241-2920
Demand History | NSN 5315-00-241-2920
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 9143M98P01 | 2025-09-269 | 55 | US |
| 5315-00-241-2920 | 2025-03-80 | 10 | US |
| 9143M98P01 | 2025-03-65 | 60 | CA |
| AN122705 | 2024-05-134 | 8 | United States |
| AN122705 | 2023-10-275 | 18 | BR |
| AN122705 | 2021-04-116 | 26 | US |
| AN122705 | 2020-03-83 | 150 | Turkey |
| AN122705 | 2018-05-135 | 1 | FX |
| AN122705 | 2017-07-207 | 250 | Turkey |
| AN122705 | 2017-03-67 | 250 | Turkey |
| 7577 | 2016-10-300 | 100 | us |
| AN122705 | 2016-08-224 | 250 | us |
| AN122705 | 2015-04-92 | 250 | Turkey |
| AN122705 | 2014-02-37 | 350 | Turkey |
| AS122705 | 2013-08-229 | 5150 | Canada |
| 5315-00-241-2920 | 2013-04-108 | 100 | MANUAL |
| AN122705 | 2012-08-216 | 25 | United States |
| 5315-00-241-2920 | 2010-01-14 | 44 | United States |
| 9143M98P01 | 2007-05-128 | 12 | US |
Cross Reference | NSN 5315-00-241-2920
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 20D12 | 0AHP5 | CURTISS-WRIGHT CONTROLS, INC DIV FLIGHT SYSTEMS |
| 7577 | 00198 | PRATT & WHITNEY CANADA CIE DIVPRATT & WHITNEY CANADA CORP. |
| 7577 | R1120 | SATAIR A/S |
| 814668-00 | 32345 | DEFENSE REDUCTION AGENCY |
| 9143M98P01 | 07482 | GENERAL ELECTRIC COMPANY DBA GE |
| AN122705 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| AS122705 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5315-00-241-2920
Related Products | NSN 5315-00-241-2920
Technical Data | NSN 5315-00-241-2920
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 1095 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 5132 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| FIRST END STYLE | 4 RADIUS |
| FIRST END CORNER RADIUS | 0.090 INCHES MINIMUM AND 0.110 INCHES MAXIMUM |
| SECOND END RELATIONSHIP WITH FIRST END | IDENTICAL |
| SURFACE FINISH | 32.0 MICROINCHES OUTSIDE DIAMETER |
| PIN OVERALL LENGTH | 0.490 INCHES MINIMUM AND 0.510 INCHES MAXIMUM |
| PIN OVERALL DIAMETER | 0.18725 INCHES MINIMUM AND 0.18775 INCHES MAXIMUM |
| MANUFACTURERS CODE | 88044 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AS122705 |
