NSN 5315-00-880-1565 4760643, 4-76064-3, 00-880-1565
Product Details | HEADLESS STRAIGHT PIN
5315-00-880-1565 A headless, cylindrically-shaped item having a straight, smooth, solid body, with or without a drilled hole(s). It has an outside diameter equal to or less than its length. Its length must not exceed twelve inches (304 MM); for items whose length exceeds twelve inches (304 MM); see ROD, STRAIGHT, HEADLESS. It is used for aligning or transfer of torque and/or thrust, by fitting into corresponding holes of another item. See also PIN, STRAIGHT, THREADED.
Part Alternates: 4760643, 4-76064-3, 5315-00-880-1565, 00-880-1565, 5315008801565, 008801565
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1960 | 00-880-1565 | 02390 ( PIN, STRAIGHT, HEADLESS ) |
Drawings & Photos | NSN 5315-00-880-1565
Demand History | NSN 5315-00-880-1565
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5315-00-880-1565 | 2026-03-82 | 20 | United States |
| 5315-00-880-1565 | 2024-09-254 | 10 | Singapore |
| 5315-00-880-1565 | 2024-09-249 | 10 | Singapore |
| 5315-00-880-1565 | 2022-06-166 | 1 | Indonesia |
| 5315-00-880-1565 | 2022-05-129 | 1 | Indonesia |
| 5315-00-880-1565 | 2020-06-174 | 3 | Indonesia |
| 5315-00-880-1565 | 2020-01-02 | 1 | Indonesia |
| 5315-00-880-1565 | 2017-03-64 | 7352 | DIBBS |
| 5315-00-880-1565 | 2015-11-321 | 9892 | DIBBS |
| 5315-00-880-1565 | 2013-08-218 | 4596 | DIBBS |
| 5315-00-880-1565 | 2013-07-211 | 11500 | DIBBS |
| 5315-00-880-1565 | 2013-07-191 | 6239 | DIBBS |
| 5315-00-880-1565 | 2013-05-151 | 4600 | DIBBS |
| 5315-00-880-1565 | 2013-03-78 | 10204 | DIBBS |
| 5315-00-880-1565 | 2013-03-71 | 100 | US |
| 5315-00-880-1565 | 2013-01-28 | 14200 | DIBBS |
| 5315-00-880-1565 | 2012-10-285 | 10802 | DIBBS |
| 5315-00-880-1565 | 2012-07-207 | 12769 | DIBBS |
| 5315-00-880-1565 | 2011-05-146 | 30 | US |
| 5315-00-880-1565 | 2010-11-314 | 5140 | DIBBS |
| 5315-00-880-1565 | 2010-04-109 | 3156 | DIBBS |
| 5315-00-880-1565 | 2009-02-53 | 26 | Singapore |
