Product Details | HEADED STRAIGHT PIN
5315-01-071-9055 A headed, cylindrically-shaped item having a solid shank for fitting into corresponding holes, used for aligning or fastening. It may have welding projections. It also may contain holes drilled perpendicular to axial centerline. Excludes PIN, ECCENTRIC.
Part Alternates: XM66965, 12285456-1, 12274634, 12285456, 5315-01-071-9055, 01-071-9055, 5315010719055, 010719055, 122854561
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 16 FEB 1979 | 01-071-9055 | 02384 ( PIN, STRAIGHT, HEADED ) |
