NSN 5315-01-451-7100 MS17984C831, MS17984-C831, 01-451-7100
Product Details | QUICK RELEASE PIN
5315-01-451-7100 A headed fastening device having a solid cylindrical or tubular body with retaining ball or pinlike detent(s). The detent(s) is/are positioned and actuated by means of a spring, elastomer or plunger. Plunger may be operated by thumb, cam or other means. May be furnished with a pull ring, pull and/or lock ring, attaching ring or hook.
Part Alternates: MS17984C831, MS17984-C831, 5315-01-451-7100, 01-451-7100, 5315014517100, 014517100
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 29 DEC 1997 | 01-451-7100 | 08323 ( PIN, QUICK RELEASE ) |
Drawings & Photos | NSN 5315-01-451-7100
Demand History | NSN 5315-01-451-7100
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS17984C831 | 2024-09-247 | 60 | United States |
| MS17984-C831 | 2022-08-235 | 2 | Canada |
| 5315-01-451-7100 | 2020-10-287 | 130 | US |
| 5315-01-451-7100 | 2019-09-268 | 54 | US |
| 5315-01-451-7100 | 2019-08-242 | 8 | United States |
| MS17984C831 | 2017-05-143 | 4 | US |
| MS17984C831 | 2016-08-214 | 6 | United States |
| MS17984C831 | 2016-05-132 | 3 | United States |
| MS17984C831 | 2016-02-34 | 90 | United States |
| MS17984C831 | 2016-01-27 | 3 | United States |
| MS17984C831 | 2014-09-265 | 6 | United States |
| MS17984C831 | 2009-09-268 | 5 | United States |
| 5315-01-451-7100 | 2009-08-219 | 6 | US |
| MS17984C831 | 2008-07-183 | 25 | us |
| MS17984C831 | 2008-03-81 | 39 | United States |
Cross Reference | NSN 5315-01-451-7100
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| MS17984-C831 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5315-01-451-7100
Technical Data | NSN 5315-01-451-7100
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 303 HANDLE STEEL COMP 630 SHANK STEEL COMP 440C DETENT STEEL COMP 630 SPINDLE STEEL COMP 303 BUTTON STEEL COMP 301 OR STEEL COMP 302 OR STEEL COMP 303 OR STEEL COMP 304 COLLAR STEEL COMP 631 OR STEEL COMP 302 RING STEEL COMP 631 OR STEEL COMP 302 SPRING |
| STYLE DESIGNATOR | Q243 BUTTON |
| SHANK DIAMETER | 0.4975 INCHES MINIMUM AND 0.4985 INCHES MAXIMUM |
| BUTTON HANDLE DIAMETER | 1.300 INCHES MINIMUM AND 1.400 INCHES MAXIMUM |
| GRIP LENGTH | 3.100 INCHES MINIMUM AND 3.120 INCHES MAXIMUM |
| SHOULDER TO HEAD END DISTANCE | 1.190 INCHES MAXIMUM |
| DETENT TO TAPERED END DISTANCE | 0.420 INCHES MINIMUM AND 0.460 INCHES MAXIMUM |
| ACTUATION TYPE | PUSH |
| ACTUATION METHOD | HANDLE |
| DETENT QUANTITY | 2 |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS17984-C831 |
Restrictions/Controls & Freight Information | NSN 5315-01-451-7100
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
