NSN 5325-01-554-2655 BACS21ED9AR, 01-554-2655, 015542655
Product Details | TURNLOCK FASTENER STUD ASSEMBLY
5325-01-554-2655 A STUD, TURNLOCK FASTENER over which may be assembled an EYELET, TURNLOCK FASTENER. Stud(s) without cam slots or cam lead threads are provided with a crosspin or eared nut for locking with the mating RECEPTACLE, TURNLOCK FASTENER. May be spring loaded. For like items having a threaded fastener, see SCREW ASSEMBLY, PANEL or SCREW, PANEL FASTENER.
Part Alternates: BACS21ED9AR, 5325-01-554-2655, 01-554-2655, 5325015542655, 015542655
Hardware and Abrasives | Fastening Devices
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 03 AUG 2007 | 01-554-2655 | 18484 ( STUD ASSEMBLY, TURNLOCK FASTENER ) |
Drawings & Photos | NSN 5325-01-554-2655
Demand History | NSN 5325-01-554-2655
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| BACS21ED9AR | 2024-09-259 | 20 | DIBBS |
| BACS21ED9AR | 2024-02-51 | 17 | DIBBS |
| BACS21ED9AR | 2023-01-17 | 70 | US |
| 5325-01-554-2655 | 2018-05-144 | 1 | DIBBS-RFPs |
| 5325-01-554-2655 | 2015-06-174 | 226 | DIBBS |
| BACS21ED9AR | 2013-08-213 | 30 | United States |
| 5325-01-554-2655 | 2012-06-163 | 181 | DIBBS |
| 5325-01-554-2655 | 2011-10-292 | 175 | DIBBS |
| 5325-01-554-2655 | 2011-09-272 | 175 | DIBBS |
| 5325-01-554-2655 | 2011-09-258 | 110 | DIBBS |
| 5325-01-554-2655 | 2011-09-258 | 17 | DIBBS |
| 5325-01-554-2655 | 2011-08-230 | 13 | DIBBS |
| 5325-01-554-2655 | 2011-08-214 | 19 | DIBBS |
| 5325-01-554-2655 | 2011-05-132 | 36 | DIBBS |
| 5325-01-554-2655 | 2011-04-118 | 31 | DIBBS |
| 5325-01-554-2655 | 2009-09-251 | 250 | US |
| BACS21ED9AR | 2008-08-214 | 3840 | US |
Cross Reference | NSN 5325-01-554-2655
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| BACS21ED9AR | 47253 | PILGRIM SCREW CORPORATION |
| BACS21ED9AR | 66530 | CLICK BOND, INC. |
| BACS21ED9AR | 73197 | HI-SHEAR CORPORATION |
| BACS21ED9AR | 77272 | THE BOEING COMPANY DBA BOEING |
| BACS21ED9AR | 81205 | THE BOEING COMPANY DBA BOEING |
| BACS21ED9AR | L4528 | LISI AEROSPACE CANADA CORP |
| BACS21ED9AR | Z03F0 | BOEING DEFENCE AUSTRALIA LTD |
| BACS21ED9AR | Z8T75 | BOEING DEFENCE AUSTRALIA LTD |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5325-01-554-2655
Related Products | NSN 5325-01-554-2655
Technical Data | NSN 5325-01-554-2655
| Characteristic | Specifications |
|---|---|
| III END ITEM IDENTIFICATION | MV-22 AIRCRAFT |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | STUD ASSY TURNLOC |
Restrictions/Controls & Freight Information | NSN 5325-01-554-2655
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5325-01-554-2655
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Materiel Management Aggregation Code | NV | TG:JOINT VERTICAL LIFT AIRCRAFT CV-22 (OSPREY) |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | V2 | MV-22 aircraft |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
