NSN 5331-00-624-1855 MS28775328, MS28775-328, MS28775328ES
Product Details | O-RING
5331-00-624-1855 A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see PACKING,PREFORMED. For noncircular items with a round cross-section, see SEAL,NONMETALLIC ROUND SECTION and RUBBER,ROUND SECTION.
Part Alternates: MS28775328, MS28775-328, MS28775328ES, MS28775-328ES, MS28784328, MS28784-328, N30475328, N304-75-328, SR 832-75-328, SR83275328, IC5181C102A3AB , P48026328, P48026-328, PRP568328406770, PRP568-328-4067-70, RE70MSBS328, RE-70-MS-BS328, 4067-70-328, 1446328, 1446-328, 177B5381PC5 , 2-328 N304-75, 2328N30475, 32175124, 32175-124, 54A125328, 54A125-328, 622731, 6227-31, 6914616328, 6914616-328, 7377328, 7377-328, 5331-00-624-1855, 00-624-1855, 5331006241855, 006241855, 406770328
Hardware and Abrasives | O-Ring
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-624-1855 | 47946 ( O-RING ) |
Drawings & Photos | NSN 5331-00-624-1855
Demand History | NSN 5331-00-624-1855
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5331-00-624-1855 | 2024-03-88 | 1265 | DIBBS |
| 5331-00-624-1855 | 2023-08-215 | 1000 | DIBBS |
| 5331-00-624-1855 | 2022-07-205 | 1000 | DIBBS |
| 5331-00-624-1855 | 2020-11-321 | 1 | DIBBS-RFPs |
| 5331-00-624-1855 | 2020-09-267 | 10 | United States |
| 32175124 | 2020-09-267 | 10 | United States |
| 5331-00-624-1855 | 2020-01-05 | 1162 | DIBBS |
| 5331-00-624-1855 | 2019-04-108 | 590 | DIBBS |
| MS28775328 | 2016-08-239 | 4 | KR |
| 5331-00-624-1855 | 2016-03-81 | 17 | MANUAL |
| N304-75-328 | 2016-03-81 | 17 | United States |
| 5331-00-624-1855 | 2014-12-350 | 2680 | DIBBS |
| MS28775328 | 2014-04-118 | 8 | Singapore |
| 5331-00-624-1855 | 2011-07-195 | 3933 | DIBBS |
| 5331-00-624-1855 | 2011-05-132 | 1105 | DIBBS |
| 5331-00-624-1855 | 2009-07-196 | 50 | United States |
| MS28775328 | 2009-07-193 | 20 | Malaysia |
Cross Reference | NSN 5331-00-624-1855
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1446-328 | 91265 | PARKER-HANNIFIN, CORPORATION DBA TECHSEAL DIVISION |
| 2-328 N304-75 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| 2-328 N304-75 | C0308 | O-RING DIVISION EUROPE |
| 32175-124 | F0189 | MESSIER-DOWTY SA |
| 4067-70-328 | 77308 | PARCO INC. |
| 5330006241855 | SCY13 | E.C.A ETABLISSEMENT CENTRALD'APPROVISIONNEMENT DES |
| 54A125-328 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 6227-31 | 07128 | COORSTEK, INC. DBA TETRAFLUOR |
| 6914616-328 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 7377-328 | 25184 | PARKER HANNIFIN CORPORATION DIV O-RING DIVISION |
| MS28775-328 | 1K697 | DBR INDUSTRIES, INC. |
| MS28775-328 | 77308 | PARCO INC. |
| MS28775-328 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| MS28775-328 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS28775-328 | D5589 | FEINMECHANISCHE WERKE MAINZ GMBH |
| MS28775-328 | D9893 | LIEBHERR-AEROSPACE LINDENBERG GMBH |
| MS28775-328ES | H2313 | ERIKS B.V. |
| MS28784-328 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MS28784-328 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| N304-75-328 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| P48026-328 | 70106 | ACUSHNET RUBBER COMPANY, INC. DBA PRECIX |
| PRP568-328-4067-70 | 77308 | PARCO INC. |
| RE-70-MS-BS328 | 0D0S3 | DTI ASSOCIATES INC |
| SR 832-75-328 | 95272 | STILLMAN SEAL CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5331-00-624-1855
Technical Data | NSN 5331-00-624-1855
| Characteristic | Specifications |
|---|---|
| MATERIAL | RUBBER BUTADIENE-ACRYLONITRILE CLASS NBR |
| CENTER HOLE DIAMETER | 1.840 INCHES MINIMUM AND 1.860 INCHES MAXIMUM |
| CROSS-SECTIONAL HEIGHT | 0.205 INCHES MINIMUM AND 0.215 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5331-00-624-1855
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 590 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5331-00-624-1855
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
