NSN 5331-00-641-1481 MS28775332, MS28775-332, MS28775332ES
Product Details | O-RING
5331-00-641-1481 A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see PACKING,PREFORMED. For noncircular items with a round cross-section, see SEAL,NONMETALLIC ROUND SECTION and RUBBER,ROUND SECTION.
Part Alternates: MS28775332, MS28775-332, MS28775332ES, MS28775-332ES, MS28784332, MS28784-332, N30475332, N304-75-332, AS568332MILP25732, AS568-332MIL-P-25732, SR 832-75-332, SR83275332, MILP25732, P48026332, P48026-332, PRP568332406770, PRP568-332-4067-70, 1446332, 1446-332, 2-332 N034-75, 2-332 N304-75, 2-332 PS1-30-5, 2332N03475, 2332N30475, 2332PS1305, 2332PSI305, 2-332PSI-30-5, 3327377, 332-7377, 4067-70-332, 622735, 6227-35, 7377332, 7377-332, 9172205 , 5331-00-641-1481, 00-641-1481, 5331006411481, 006411481, 406770332
Hardware and Abrasives | O-Ring
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-641-1481 | 47946 ( O-RING ) |
Drawings & Photos | NSN 5331-00-641-1481
Demand History | NSN 5331-00-641-1481
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MILP25732 | 2023-09-261 | 15 | US |
| MILP25732 | 2023-09-261 | 15 | US |
| 5331-00-641-1481 | 2017-12-352 | 5742 | DIBBS |
| 5331-00-641-1481 | 2017-08-226 | 2832 | DIBBS |
| 5331-00-641-1481 | 2017-02-53 | 11 | MANUAL |
| 5331-00-641-1481 | 2014-06-153 | 2628 | DIBBS |
| 5331-00-641-1481 | 2012-09-248 | 2400 | DIBBS |
| 5331-00-641-1481 | 2012-04-110 | 1000 | DIBBS |
| 5331-00-641-1481 | 2012-03-79 | 400 | DIBBS |
| 5331-00-641-1481 | 2012-02-55 | 406 | DIBBS |
| 5331-00-641-1481 | 2009-01-20 | 708 | DIBBS |
| 2332N30475 | 2007-10-284 | 1 | us |
| MS28775332 | 2007-03-78 | 4 | SE |
Cross Reference | NSN 5331-00-641-1481
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1446-332 | 91265 | PARKER-HANNIFIN, CORPORATION DBA TECHSEAL DIVISION |
| 15332865 | K6451 | BAE SYSTEMS MARINE LIMITED |
| 2-332 N034-75 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| 2-332 N304-75 | C0308 | O-RING DIVISION EUROPE |
| 2-332 PS1-30-5 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| 2-332PSI-30-5 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| 332-7377 | 25184 | PARKER HANNIFIN CORPORATION DIV O-RING DIVISION |
| 4067-70-332 | 77308 | PARCO INC. |
| 5330006411481 | SCY13 | E.C.A ETABLISSEMENT CENTRALD'APPROVISIONNEMENT DES |
| 6227-35 | 07128 | COORSTEK, INC. DBA TETRAFLUOR |
| 7377-332 | 25184 | PARKER HANNIFIN CORPORATION DIV O-RING DIVISION |
| AS568-332MIL-P-25732 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| MILP25732 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MS28775-332 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| MS28775-332 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS28775-332ES | H2313 | ERIKS B.V. |
| MS28784-332 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| N304-75-332 | 02697 | PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER |
| P48026-332 | 70106 | ACUSHNET RUBBER COMPANY, INC. DBA PRECIX |
| PRP568-332-4067-70 | 77308 | PARCO INC. |
| SR 832-75-332 | 95272 | STILLMAN SEAL CORPORATION |
| SR 832-75-332 | SW461 | HUTCHINSON SEAL DE MEXICO STILLMAN SEAL DIVISION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5331-00-641-1481
Technical Data | NSN 5331-00-641-1481
| Characteristic | Specifications |
|---|---|
| MATERIAL | RUBBER BUTADIENE-ACRYLONITRILE CLASS NBR |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-P-25732 MIL SPEC SINGLE MATERIAL RESPONSE |
| TEMP RATING | 275.0 DEG FAHRENHEIT |
| CENTER HOLE DIAMETER | 2.340 INCHES MINIMUM AND 2.360 INCHES MAXIMUM |
| CROSS-SECTIONAL HEIGHT | 0.205 INCHES MINIMUM AND 0.215 INCHES MAXIMUM |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILP25732 |
Restrictions/Controls & Freight Information | NSN 5331-00-641-1481
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | Y | 180 months |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194120 | WASHERS/GASKETS/PCKG DVCS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
