NSN 5331-00-691-0145 MS28775022, MS28775-022, MS28775022ES

Product Details | O-RING

5331-00-691-0145 A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see PACKING,PREFORMED. For noncircular items with a round cross-section, see SEAL,NONMETALLIC ROUND SECTION and RUBBER,ROUND SECTION.

Part Alternates: MS28775022, MS28775-022, MS28775022ES, MS28775-022ES, AS28775022, AS28775-022 , ASC1100725, SR 832-75-022, SR 832-75-22, SR83275022, SR8327522, W 4072 434 AL, W4072434AL, P48026022, P48026-022, PRP568022406770, PRP568-022-4067-70, RY-155615PC 22, RY155615PC22, I101260SR83275, I101260SR832-75, I16560SR83275, I16560SR832-75, MILP25732, 4067-70-022, 40677022, 4067-70-22, 7377022, 7377-022, 737722, 7377-22, 1376-23-170, 1446022, 1446-022, 2-022 N304-75, 2022N30475, 2222N75675, 2-222N756-75, 10075107 , 2300-79016, 25.12X1.78-24B7, 2512X17824B7, 2512X178SR83275, 5331-00-691-0145, 00-691-0145, 5330006910145 , 5331006910145, 006910145, 137623170, 406770022, 230079016

Hardware and Abrasives | O-Ring

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
53	01 JAN 1963	00-691-0145	47946 ( O-RING )

Drawings & Photos | NSN 5331-00-691-0145

Part Number	Request Date	QTY	Origin
5331-00-691-0145	2025-09-265	2	US
5331-00-691-0145	2025-02-34	10000	DIBBS
5331-00-691-0145	2025-01-23	10000	DIBBS
5331-00-691-0145	2024-09-266	6000	DIBBS
MS28775022	2024-02-36	20	Croatia
MILP25732	2023-09-261	15	US
MILP25732	2023-09-261	15	US
5331-00-691-0145	2023-01-23	4030	DIBBS
5331-00-691-0145	2022-12-362	686	DIBBS
5331-00-691-0145	2022-12-342	3125	DIBBS
5331-00-691-0145	2022-10-276	9000	DIBBS
5331-00-691-0145	2022-09-265	9000	DIBBS
5331-00-691-0145	2022-07-199	16625	DIBBS
5331-00-691-0145	2022-07-188	16625	DIBBS
MS28775022	2021-11-313	25	us
5331-00-691-0145	2021-10-287	3125	DIBBS
5331-00-691-0145	2021-07-189	3125	DIBBS
5331-00-691-0145	2021-06-175	3125	DIBBS
5331-00-691-0145	2021-04-116	3125	DIBBS
5331-00-691-0145	2021-04-91	3125	DIBBS
5331-00-691-0145	2021-03-63	3125	DIBBS
5331-00-691-0145	2021-02-38	9288	DIBBS
5331-00-691-0145	2021-01-04	25	Taiwan
MS28775022	2020-08-230	9	Malaysia
MS28775022	2020-06-157	24	us
5331-00-691-0145	2019-10-281	17	Taiwan
5331-00-691-0145	2019-09-272	17	Taiwan
5331-00-691-0145	2019-09-267	17	Taiwan
5331-00-691-0145	2019-09-260	17	TW
MS28775-022	2017-03-72	1
MS28775022	2017-03-60	33	United States
MS28775-022	2017-02-53	15
2-222N756-75	2016-03-81	189	United States
5331-00-691-0145	2016-03-81	189	MANUAL
25	2016-01-04	2	United States
25	2013-08-214	1	US
MS28775022	2012-05-143	1	United States
5330-00-691-0145	2008-11-311	60	IT
5331-00-691-0145	2008-06-154	4726	DIBBS

Cross Reference | NSN 5331-00-691-0145

Part Number	Cage Code	Manufacturer
1376-23-170	A0199	OTO MELARA SPA
1446-022	91265	PARKER-HANNIFIN, CORPORATION DBA TECHSEAL DIVISION
2-022 N304-75	02697	PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER
2-022 N304-75	C0308	O-RING DIVISION EUROPE
2-222N756-75	02697	PARKER-HANNIFIN CORPORATION DBA O'RING DIVISION OF PARKER
2300-79016	A0199	OTO MELARA SPA
25,12X1,78-24B7	F0229	LE JOINT FRANCAIS
25,12X1,78SR832-75	F0229	LE JOINT FRANCAIS
25.12X1.78-24B7	F8226	SOCIETE TECHNIQUE ARMORICAINE DECAOUTCHOUC ET ELASTOMERES
4067-70-022	77308	PARCO INC.
4067-70-22	77308	PARCO INC.
5330006910145	SCY13	E.C.A ETABLISSEMENT CENTRALD'APPROVISIONNEMENT DES
7377-022	25184	PARKER HANNIFIN CORPORATION DIV O-RING DIVISION
7377-22	25184	PARKER HANNIFIN CORPORATION DIV O-RING DIVISION
AS28775-022	1K697	DBR INDUSTRIES, INC.
ASC1100725	Z4779	ASC PTY LTD
I101260SR832-75	F0229	LE JOINT FRANCAIS
I16560SR832-75	F0229	LE JOINT FRANCAIS
MILP25732	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MS28775-022	81343	SOCIETY OF AUTOMOTIVE ENGINEERS INC
MS28775-022	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS28775-022	F0229	LE JOINT FRANCAIS
MS28775-022ES	H2313	ERIKS B.V.
P48026-022	70106	ACUSHNET RUBBER COMPANY, INC. DBA PRECIX
PRP568-022-4067-70	77308	PARCO INC.
RY-155615PC 22	93232	CURTISS-WRIGHT ELECTRO-MECHANICAL CORPORATION
SR 832-75-022	95272	STILLMAN SEAL CORPORATION
SR 832-75-22	95272	STILLMAN SEAL CORPORATION
W 4072 434 AL	S3092	RHEINMETALL AIR DEFENCE AG

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5331-00-691-0145

Compare

Related Products | NSN 5331-00-691-0145

5331-00-691-0653, 5331-00-691-6342, 5331-00-691-6345, 5331-00-691-7916, 5331-00-691-8143

Technical Data | NSN 5331-00-691-0145

Characteristic	Specifications
MATERIAL	RUBBER BUTADIENE-ACRYLONITRILE CLASS NBR
CENTER HOLE DIAMETER	0.979 INCHES MINIMUM AND 0.999 INCHES MAXIMUM
CROSS-SECTIONAL HEIGHT	0.067 INCHES MINIMUM AND 0.073 INCHES MAXIMUM
MANUFACTURERS CODE	81349
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	MILP25732

Restrictions/Controls & Freight Information | NSN 5331-00-691-0145

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	Y	180 months
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

Category	Code	Description
NMF Description	194120	WASHERS/GASKETS/PCKG DVCS NOI
Less than car load rating
Less than truck load rating	W	Rating Variable
Water commodity Code	596	unknown
Originating Activity Code	XX
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	V	Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 5331-00-691-0145

Category	Code	Description
Materiel Category and Inventory Manager	T	Industrial Supplies (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	B	Rotary Wing Aircraft
Weapons Systems/End Item or Homogeneous Group	BJ	AH-64 Airframe
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	Y	180 months
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Materiel Management Aggregation Code	SX	SX:AF SICA RESIDUAL MMAC-OC-ALC
Price Validation	V	The current standard price has been validated. The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range. The item was procured under open competition and under the competitive arena the price is considered fair and reasonable. ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	Y	180 months
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Stores Account Code	1	Marine Corps Stock Fund Account Item.
Combat Essentiality Code	5	Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency.
Materiel Management Code	B	All CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code	2	ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DM	U.S. Marine Corps
Service Organization	M	U.S. Marine Corps
Reparability	Z	Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	Y	180 months
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	Y	180 months
Purchasing	QTY UOM	1 EA : Each
