NSN 5331-01-541-1857 M83248/1-275, M83248/1-275D4, M832481275
Product Details | O-RING
5331-01-541-1857 A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see PACKING,PREFORMED. For noncircular items with a round cross-section, see SEAL,NONMETALLIC ROUND SECTION and RUBBER,ROUND SECTION.
Part Alternates: M83248/1-275, M83248/1-275D4, M832481275, M832481275D4, 6392604-01 FIND 012, 639260401FIND012, 6393516 FIND 68, 6393516 FIND 68D4, 6393516FIND68, 6393516FIND68D4, 5331-01-541-1857, 01-541-1857, 5331015411857, 015411857
Hardware and Abrasives | O-Ring
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 19 JUN 2006 | 01-541-1857 | 47946 ( O-RING ) |
Drawings & Photos | NSN 5331-01-541-1857
Cross Reference | NSN 5331-01-541-1857
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 6392604-01 FIND 012 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 6393516 FIND 68 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 6393516 FIND 68D4 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| M83248/1-275 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M83248/1-275D4 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5331-01-541-1857
Technical Data | NSN 5331-01-541-1857
| Characteristic | Specifications |
|---|---|
| DEPARTURE FROM CITED DESIGNATOR | QUALITY ASSURANCE TESTED AND CERTIFIED FOR DEEP SUBMERGENCE SYSTEMS; CRITICAL ITEMS FOR SAFETY AND SURVIVAL OF DEEP SUBMERGENCE RESEARCH AND RESCUE VEHICLES AS DIFFERENTIATED BY SPECIAL TEST FEATURES |
| CRITICALITY CODE JUSTIFICATION | ZZZX |
| III END ITEM IDENTIFICATION | MOTOR CONTROLLER THRUSTER SUBASSEMBLY |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M83248/1-275 |
Restrictions/Controls & Freight Information | NSN 5331-01-541-1857
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | S | The item is a non-aviation Critical Safety Item (CSI) whose failure will result in serious damage to equipment or serious injury or death to personnel. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5331-01-541-1857
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 1H | Consumable material assigned to NAVICP MECH for inventory management Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | D4 | An item that supports the Deep Submergence Program and is considered Scope of Certification MCD "B" material. Each item has undergone Receipt Inspection to insure it meets the requirements of the applicable specification and /or drawing and is certified for use in DSS-SOC applications. Items shall have 10.3-140 CODEIDENTIFIES ITEMS WITH PREDOMINANT APPLICATION TO:serialization markings identified on a securely attached Ready For Issue (RFI) tag. |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | M | Medium Demand Velocity Items (consumables) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
