Product Details | SEALING PLUG ASSEMBLY
5340-00-570-3734 An item consisting of a cylindrical plug which may be grooved and a driving element such as a tapered drive pin, a ball or the like which widens the plug. The plug is designed to close a hole in an item and thus prevent liquid from leaking out.
Part Alternates: C117360005, C11736-0005, S8187001, S8-187001, SP780004, SP780-004, ST7M141D6S, PLGA1870010, PLGA1870010A, 093-49831-6, 10117403 , 1223805, 1223-805, 132D1076 , 187001, 1870010, 5340-00-570-3734, 00-570-3734, 5340005703734, 093498316, 005703734
