NSN 5340-00-982-5682 3386, 00-982-5682, 009825682
Product Details | RIGID CASTER
5340-00-982-5682 A caster designed to maintain the rotation of the wheel(s) or spherical constructed item in one plane.
Part Alternates: 3386, 5340-00-982-5682, 00-982-5682, 5340009825682, 009825682
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1962 | 00-982-5682 | 06187 ( CASTER, RIGID ) |
Drawings & Photos | NSN 5340-00-982-5682
Cross Reference | NSN 5340-00-982-5682
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 3386 | 06004 | STEWART-WARNER BASSICK CORP |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-00-982-5682
Related Products | NSN 5340-00-982-5682
Technical Data | NSN 5340-00-982-5682
| Characteristic | Specifications |
|---|---|
| MATERIAL AND LOCATION | RUBBER WHEEL RIM RUBBER TREAD |
| SAFE OPERATING LOAD RATING | 125.0 POUNDS NOMINAL |
| STYLE DESIGNATOR | 1 RIGID |
| WHEEL DIAMETER | 3.000 INCHES NOMINAL |
| TREAD WIDTH | 1.312 INCHES NOMINAL |
| EFFECTIVE HEIGHT | 3.688 INCHES NOMINAL |
| PLATE STYLE | 2 RECTANGULAR |
| CENTER TO CENTER DISTANCE BETWEEN BOLT HOLES ALONG WIDTH | 1.188 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN BOLT HOLES ALONG LENGTH | 4.000 INCHES NOMINAL |
| CASTER PLATE LENGTH | 5.000 INCHES NOMINAL |
| CASTER PLATE WIDTH | 2.500 INCHES NOMINAL |
| CASTER PLATE MOUNTING HOLE DIAMETER | 0.344 INCHES NOMINAL |
| WHEEL BEARING TYPE | PLAIN, SELF-LUBRICATED |
| WHEEL QUANTITY | 1 |
| WHEEL TYPE | BUILT UP |
Restrictions/Controls & Freight Information | NSN 5340-00-982-5682
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
