NSN 5342-01-169-3048 HT012412, HT01241-2, ST9M626H2
Product Details | WEAPON SYSTEM RESILIENT MOUNT
5342-01-169-3048 An item made of material having elastic properties. It may have rigid mounting facilities such as a flange(s), sleeve(s), stud(s) or the like. It is designed to isolate or dampen shock and/or vibration of a continuous or intermittent origin and serve as a support for a weapon system component to be isolated. Excludes MOUNT, RESILIENT, UTILITY; SPRING (as modified); BUMPER, NONMETALLIC; BUMPER, RUBBER; BUSHING, NONMETALLIC; hydraulic and pneumatic shock absorbers, dash-pots, grommets, and shock pads.
Part Alternates: HT012412, HT01241-2, ST9M626H2, 23914H2, 23914-H2 , 5342-01-169-3048, 01-169-3048, 5342011693048, 011693048
Hardware and Abrasives | Hardware, Weapon System
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 06 JAN 1984 | 01-169-3048 | 53589 ( MOUNT, RESILIENT, WEAPON SYSTEM ) |
Drawings & Photos | NSN 5342-01-169-3048
Demand History | NSN 5342-01-169-3048
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 23914-H2 | 2025-11-313 | 21 | DIBBS |
| 23914-H2/03 | 2025-11-313 | 21 | DIBBS |
| ST9M626H2 | 2025-11-313 | 21 | DIBBS |
| 23914-H2 | 2025-04-92 | 74 | DIBBS |
| 23914-H2/03 | 2025-04-92 | 74 | DIBBS |
| ST9M626H2 | 2025-04-92 | 74 | DIBBS |
| 23914-H2 | 2025-03-84 | 74 | DIBBS |
| 23914-H2/03 | 2025-03-84 | 74 | DIBBS |
| ST9M626H2 | 2025-03-84 | 74 | DIBBS |
| 23914-H2 | 2024-10-278 | 6 | DIBBS |
| 23914-H2/03 | 2024-10-278 | 6 | DIBBS |
| ST9M626H2 | 2024-10-278 | 6 | DIBBS |
| 23914-H2 | 2024-09-269 | 6 | DIBBS |
| 23914-H2/03 | 2024-09-269 | 6 | DIBBS |
| ST9M626H2 | 2024-09-269 | 6 | DIBBS |
| 5342-01-169-3048 | 2022-12-348 | 4 | US |
| 5342-01-169-3048 | 2020-06-168 | 2 | us |
| 5342-01-169-3048 | 2020-06-164 | 2 | us |
| 23914H2 | 2020-01-15 | 4 | United States |
| 23914-H2 | 2019-09-262 | 198 | DIBBS |
| 23914-H2/30 | 2019-09-262 | 198 | DIBBS |
| ST9M626H2 | 2019-09-262 | 198 | DIBBS |
| 23914H2 | 2019-04-93 | 79 | DIBBS |
| 23914-H2 | 2019-04-93 | 79 | DIBBS |
| ST9M626H2 | 2019-04-93 | 79 | DIBBS |
| 5342-01-169-3048 | 2018-05-149 | 73 | DIBBS |
| ST9M626H2 | 2017-06-170 | 16 | United States |
| 5342-01-169-3048 | 2014-05-130 | 258 | DIBBS |
| 5342-01-169-3048 | 2014-05-121 | 258 | DIBBS |
| 5342-01-169-3048 | 2014-04-93 | 22 | DIBBS |
| 5342-01-169-3048 | 2013-10-275 | 76 | DIBBS |
| 5342-01-169-3048 | 2011-10-304 | 96 | DIBBS |
| ST9M626H2 | 2010-10-301 | 240 | IN |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5342-01-169-3048
Related Products | NSN 5342-01-169-3048
Technical Data | NSN 5342-01-169-3048
| Characteristic | Specifications |
|---|---|
| RESILIENT MEMBER MATERIAL | SILICONE RUBBER |
| NONMETALLIC HARDNESS RATING | NOT RATED |
| RIGID MEMBER MATERIAL AND LOCATION | ALUMINUM ALLOY, QQ-A-225/5, ALLOY 2017 INNER MEMBER OR ALUMINUM ALLOY, QQ-A-225/6, ALLOY 2024 INNER MEMBER ALUMINUM ALLOY,QQ-A-371,ALLOY 380 HOLDER ALUMINUM ALLOY,QQ-A-250,ALLOY 2024,TEMPER T4 WASHER |
| RIGID MEMBER SURFACE TREATMENT AND LOCATION | ANODIZED, MIL-A-8625, TYPE 2 INNER MEMBER OR CHROMATE, MIL-C-5541 INNER MEMBER ANODIZED, MIL-A-8625, TYPE 2 WASHER OR CHROMATE, MIL-C-5541 WASHER LACQUER, TT-L-32 HOLDER |
| DISTANCE BETWEEN MOUNTING HOLE CENTERS | 1.402 INCHES MINIMUM AND 1.410 INCHES MAXIMUM |
| FLANGE LENGTH | 1.810 INCHES NOMINAL |
| FLANGE WIDTH | 1.330 INCHES NOMINAL |
| FLANGE MOUNTING HOLE DIAMETER | 0.195 INCHES MINIMUM AND 0.200 INCHES MAXIMUM |
| HEIGHT | 1.090 INCHES MINIMUM AND 1.150 INCHES MAXIMUM |
| LOAD/FREQUENCY RANGE | RANGE NOT SPECIFIED |
| MAXIMUM LOAD RATING | 2.0 POUNDS |
| SPECIAL FEATURES | 2 MTG HOLES COUNTERSUNK 100 DEG 0.300 IN. MIN 0.320 IN. MAX DP |
| MANUFACTURERS CODE | 76301 |
| MFR SOURCE CONTROLLING REFERENCE | ST9M626H2 |
