NSN 5355-01-162-8635 3120W85P005, 01-162-8635, 011628635
Product Details | SCALE DIAL
5355-01-162-8635 A dial designed to be read in conjunction with a vernier indicator, pointer(s) or like instruments, which device is not an integral part of the item. The item does not have facilities for connection to a tuning or selection mechanism to position the mechanism. However, it may be designed to be mounted on a knob used to position the mechanism. Excludes SCALEPLATE, ELECTRICAL METER. See also DIAL, CONTROL.
Part Alternates: 3120W85P005, 5355-01-162-8635, 01-162-8635, 5355011628635, 011628635
Hardware and Abrasives | Knobs and Pointers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 23 SEP 1983 | 01-162-8635 | 03264 ( DIAL, SCALE ) |
Drawings & Photos | NSN 5355-01-162-8635
Demand History | NSN 5355-01-162-8635
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5355-01-162-8635 | 2022-11-327 | 3 | United States |
| 5355-01-162-8635 | 2022-09-245 | 5 | United States |
| 5355-01-162-8635 | 2022-08-243 | 1 | DIBBS |
| 5355-01-162-8635 | 2022-08-226 | 3 | DIBBS |
| 5355-01-162-8635 | 2022-06-153 | 2 | DIBBS |
| 5355-01-162-8635 | 2022-04-108 | 1 | DIBBS |
| 5355-01-162-8635 | 2021-11-306 | 1 | DIBBS |
| 5355-01-162-8635 | 2021-10-278 | 1 | DIBBS |
| 5355-01-162-8635 | 2020-01-29 | 1 | DIBBS |
| 5355-01-162-8635 | 2020-01-20 | 1 | DIBBS |
| 5355-01-162-8635 | 2018-06-157 | 1 | DIBBS |
| 5355-01-162-8635 | 2018-05-149 | 1 | DIBBS |
| 5355-01-162-8635 | 2015-11-327 | 15 | Canada |
| 5355-01-162-8635 | 2015-08-230 | 2 | DIBBS |
| 5355-01-162-8635 | 2015-08-217 | 2 | DIBBS |
| 5355-01-162-8635 | 2013-06-156 | 11 | DIBBS |
Cross Reference | NSN 5355-01-162-8635
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 3120W85P005 | 97424 | AMETEK, INC. DIV AEROSPACE & DEFENSE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5355-01-162-8635
Technical Data | NSN 5355-01-162-8635
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A91 ROUND |
| SCALE DIRECTION AND RANGE | 0 TO 20 COUNTERCLOCKWISE SINGLE SCALE |
| SCALE TYPE | NONLINEAR SINGLE SCALE |
| SCALE DIVISION QUANTITY | 22 SINGLE SCALE |
| SPECIAL FEATURES | ATTACHMENT METHOD: SETSCREWS; SETSCREW HOLE QUANTITY: 2 |
| (NON-CORE DATA) SCALE DISTANCE AND TYPE | 3.017 INCHES CIRCULAR |
| MANUFACTURERS CODE | 97424 |
| DESIGN CONTROL REFERENCE | 3120W85P005 |
Restrictions/Controls & Freight Information | NSN 5355-01-162-8635
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5355-01-162-8635
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
