Product Details | EXTENSION SHAFT
5355-01-169-2957 An item consisting of a length of rigid shafting designed to be coupled to the shaft of items such as variable capacitors, switches, hand cranks and the like. It is specifically designed to increase the length of the original shaft and may also effect a change in the shaft diameter. Includes coupling(s) or has processed end(s) to facilitate the attachment of a coupling device. May have provision for electrically insulating the extension shaft from the other shaft.
Part Alternates: 011692957
Mechanical Power Transmission Equipment | Miscellaneous Power Transmission Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 30 | 06 JAN 1984 | 01-169-2957 | 18437 ( EXTENSION SHAFT ) |
Demand History | NSN 5355-01-169-2957
Cross Reference | NSN 5355-01-169-2957
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2078 | 52326 | LEIDOS, INC. DBA LEIDOS - CYBERSECURITY |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5355-01-169-2957
Related Products | NSN 5355-01-169-2957
3040-01-184-4323, 3040-01-186-1649, 3040-01-198-2870, 3040-01-200-1336, 3040-01-200-6208
Technical Data | NSN 5355-01-169-2957
| Characteristic | Specifications |
|---|---|
| SHAFT END DIAMETER | 0.248 INCHES MINIMUM AND 0.249 INCHES MAXIMUM |
| MATERIAL | STEEL COMP 303 |
| SHAFT END CONFIGURATION | FLATTED ROUND |
| SURFACE TREATMENT | PASSIVATE |
| SHAFT END DESIGN | MALE |
| OUTSIDE DIAMETER | 0.500 INCHES NOMINAL |
| END TYPE | INTEGRAL COUPLING |
| THREAD SERIES DESIGNATOR | UNC SCREW HOLE |
| LENGTH | 1.600 INCHES NOMINAL |
| THREAD QUANTITY PER INCH | 32 SCREW HOLE |
| SOCKET DEPTH | 0.400 INCHES NOMINAL |
| SOCKET DIAMETER | 0.249 INCHES MINIMUM AND 0.250 INCHES MAXIMUM |
| STYLE DESIGNATOR | PLAIN SOCKET |
| NOMINAL THREAD SIZE | 0.138 INCHES SCREW HOLE |
| SHOULDER LENGTH | 0.680 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5355-01-169-2957
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 126900 | POWER TRANS SHAFTING/SHAFTS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5355-01-169-2957
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
