NSN 5360-00-063-4146 171PCS104A , 48089043, 9534106
Product Details | TORSION HELICAL SPRING
5360-00-063-4146 An open-or close-wound coil spring consisting of one or more helical coils, wound from different shapes and types of material and finished at the ends, designed to exert pressure in a rotating direction around the coil axis. Excludes springs designed for thermal actuation (springs in which the torsion forces are counteracted by changes in temperature) and SPRING, REINFORCING, HOSE.20210050018Guns, through 30mm53600034Coil, Flat, Leaf, and Wire Springs
Part Alternates: 171PCS104A , 48089043, 9534106, 5360-00-063-4146, 00-063-4146, 5360000634146, 000634146
Hardware and Abrasives | Coil, Flat, Leaf, and Wire Springs
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 19 NOV 1972 | 00-063-4146 | 04228 ( SPRING, HELICAL, TORSION ) |
Drawings & Photos | NSN 5360-00-063-4146
Demand History | NSN 5360-00-063-4146
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5360-00-063-4146 | 2012-08-237 | 65 | DIBBS |
| 5360-00-063-4146 | 2012-08-225 | 3 | DIBBS |
| 5360-00-063-4146 | 2012-07-198 | 66 | DIBBS |
| 5360-00-063-4146 | 2012-06-173 | 66 | DIBBS |
| 5360-00-063-4146 | 2012-06-167 | 80 | DIBBS |
| 9534106 | 2012-05-142 | 100 | Turkey |
| 5360-00-063-4146 | 2012-04-101 | 52 | DIBBS |
| 5360-00-063-4146 | 2011-08-221 | 66 | DIBBS |
| 5360-00-063-4146 | 2011-05-125 | 35 | DIBBS |
| 171PCS104A | 2007-07-189 | 15 | Australia |
Cross Reference | NSN 5360-00-063-4146
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 48089043 | 81873 | WOODWARD HRT, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5360-00-063-4146
Technical Data | NSN 5360-00-063-4146
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 302 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 5688D ASSN STD SINGLE MATERIAL RESPONSE OR QQ-W-423, COND B FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | PASSIVATE OVERALL |
| STYLE DESIGNATOR | C1A SINGLE TORSION LEFT HAND |
| INSIDE DIAMETER | 0.065 INCHES MINIMUM AND 0.070 INCHES MAXIMUM |
| SPRING FREE LENGTH | 0.250 INCHES NOMINAL |
| SPRING FREE OUTSIDE DIAMETER | 0.123 INCHES MINIMUM AND 0.128 INCHES MAXIMUM |
| HOOK RADIUS | 0.033 INCHES MINIMUM AND 0.034 INCHES MAXIMUM FIRST END |
| END LENGTH | 0.150 INCHES NOMINAL FIRST END 0.170 INCHES NOMINAL SECOND END |
| END LENGTH FROM FIRST BEND TO SECOND BEND OR END | 0.130 INCHES NOMINAL SECOND END |
| END LENGTH FROM SECOND BEND TO THIRD BEND OR END | 0.135 INCHES MINIMUM AND 0.138 INCHES MAXIMUM SECOND END |
| HOOK LEG LENGTH | 0.139 INCHES NOMINAL FIRST END |
| END STYLE | G18 OFFSET HALF LOOP, LEFT END FIRST END G31 ANGULAR SECOND END |
| COIL HELIX DIRECTION | RIGHT-HAND OR LEFT-HAND |
| STOCK DIAMETER | 0.029 INCHES NOMINAL |
| COIL QUANTITY | 7 |
| END ANGULAR RELATIONSHIP | ENDS ANGLED ONE TO OTHER |
Restrictions/Controls & Freight Information | NSN 5360-00-063-4146
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062960 | REOSTATS/PARTS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 659 | unknown |
| Originating Activity Code | SG | 403 SCMS/GUED 5215 Thurlow St, Suite 5, Bldg 70C Wright-Patterson AFB OH 45433 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
