NSN 5360-00-092-9469 24432, 24-432, 00-092-9469
Product Details | EXTENSION GARTER SPRING
5360-00-092-9469 A close-coiled helical extension spring, with ends fastened together to form a circle, designed to impose compression stresses toward the center of the circle thus formed when uniformly expanded.
Part Alternates: 24432, 24-432, 5360-00-092-9469, 00-092-9469, 5360000929469, 000929469
Hardware and Abrasives | Coil, Flat, Leaf, and Wire Springs
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-092-9469 | 04225 ( SPRING, GARTER, EXTENSION ) |
Cross Reference | NSN 5360-00-092-9469
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 24-432 | 96152 | BORG-WARNER CORP MARVEL-SCHEBLER/TILLOTSON DIV |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5360-00-092-9469
Technical Data | NSN 5360-00-092-9469
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| INSIDE DIAMETER | 0.593 INCHES MINIMUM AND 0.633 INCHES MAXIMUM |
| SPRING FREE OUTSIDE DIAMETER | 0.799 INCHES MINIMUM AND 0.849 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5360-00-092-9469
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
