NSN 5365-01-297-2790 MILS22499, MIL-S-22499, 55977881
Product Details | SHIM
5365-01-297-2790 A thin flat metal or plastic item of various peripheral shapes having a solid or laminated cross-section. It is designed to maintain a predetermined distance between two surfaces. For round items without a hole and having a solid rectangular cross-section use DISK, SOLID, PLAIN. Items with either (1) a solid (not laminated) cross-section, or (2) a non-separable laminated cross-section with one hole centrally located, must have a thickness less than 0.006 inch (0.152 mm) for items less than 1/4 inch (6.35 mm) outside diameter or shortest distance across peripheral flats, and less than 0.016 inch (0.406 mm) for items 1/4 inch (6.35 mm) or more outside diameter, or shortest distance across peripheral flats. For items with thickness greater than those indicated above, see SPACER, PLATE; WASHER, FLAT and SPACER, RING. When thickness and/or outside diameter or shortest distance across peripheral flats is designated as a tolerance dimension, the maximum dimension will be used to determine compliance. See also SHIM STOCK, LAMINATED; SHIM STOCK ASSORTMENT, GASKET; and BEARING, WASHER, THRUST.
Part Alternates: MILS22499, MIL-S-22499, 55977881, 5597788-1, 55977882, 5597788-2, 5365-01-297-2790, 01-297-2790, 5365012972790, 012972790
Hardware and Abrasives | Bushings, Rings, Shims, and Spacers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 31 MAR 1989 | 01-297-2790 | 20349 ( SHIM ) |
Drawings & Photos | NSN 5365-01-297-2790
Demand History | NSN 5365-01-297-2790
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MILS22499 | 2026-02-48 | 5 | US |
| 5365-01-297-2790 | 2025-06-154 | 30 | France |
| MILS22499 | 2023-02-37 | 1 | United States |
| 55977882 | 2022-10-291 | 16 | United States |
| 5365-01-297-2790 | 2020-07-198 | 2 | us |
| MILS22499 | 2020-05-140 | 1 | US |
| 5365-01-297-2790 | 2020-01-24 | 4 | Spain |
| 5365-01-297-2790 | 2018-12-361 | 3019 | DIBBS |
| 5365-01-297-2790 | 2018-07-185 | 1878 | DIBBS |
| 5365-01-297-2790 | 2018-04-101 | 545 | DIBBS |
| 5365-01-297-2790 | 2017-08-221 | 356 | DIBBS |
| 5365-01-297-2790 | 2017-02-52 | 388 | DIBBS |
| 5365-01-297-2790 | 2017-02-37 | 236 | DIBBS |
| 5365-01-297-2790 | 2017-01-29 | 236 | DIBBS |
| 5365-01-297-2790 | 2015-01-11 | 614 | DIBBS |
| 5365-01-297-2790 | 2014-12-350 | 370 | DIBBS |
| 5365-01-297-2790 | 2013-10-281 | 493 | DIBBS |
| 5365-01-297-2790 | 2013-08-219 | 241 | DIBBS |
| 5365-01-297-2790 | 2013-04-91 | 274 | DIBBS |
| 5365-01-297-2790 | 2013-03-83 | 274 | DIBBS |
| 5365-01-297-2790 | 2012-01-27 | 268 | DIBBS |
| 5365-01-297-2790 | 2010-06-160 | 50 | DIBBS |
| MILS22499 | 2009-02-43 | 3 | US |
| 5365-01-297-2790 | 2009-02-35 | 297 | DIBBS |
| 5365-01-297-2790 | 2008-09-247 | 201 | DIBBS |
| 5365-01-297-2790 | 2008-07-191 | 50 | DIBBS |
| 5365-01-297-2790 | 2008-06-163 | 54 | DIBBS |
| 5365-01-297-2790 | 2008-05-133 | 65 | DIBBS |
Cross Reference | NSN 5365-01-297-2790
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 5597788-1 | 38597 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 5597788-1 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 5597788-1 | 5D286 | LOCKHEED MARTIN CORP LOCKHEED MARTIN LABORATORIES |
| 5597788-2 | 38597 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 5597788-2 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 5597788-2 | 5D286 | LOCKHEED MARTIN CORP LOCKHEED MARTIN LABORATORIES |
| MIL-S-22499 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
