NSN 5920-00-913-2897 284006, 43.1608, 431608
Product Details | EXTRACTOR POST FUSEHOLDER
5920-00-913-2897 A fuseholder in which the clips or contacts for electrical connection to the fuse are mounted in a tubular body or similar inclosure which surrounds the fuse. It generally contains a removable cap or knob. It includes in-the-line type and those designated as miniature type FUSEHOLDER (as modified).
Part Alternates: 284006, 43.1608, 431608, 5L485100177, 5L4851-001-77, 5920-00-913-2897, 00-913-2897, 5920009132897, 009132897, 413033282
Electrical and Electronic Equipment Components | Fuses, Arrestors, Absorbers, and Protectors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-913-2897 | 28909 ( FUSEHOLDER, EXTRACTOR POST ) |
Drawings & Photos | NSN 5920-00-913-2897
Demand History | NSN 5920-00-913-2897
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 284006 | 2011-05-144 | 22 | Japan |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5920-00-913-2897
Technical Data | NSN 5920-00-913-2897
| Characteristic | Specifications |
|---|---|
| FUSE ACCOMMODATION QUANTITY | 1 |
| CURRENT CARRYING RATING IN AMPS | 5.0 |
| VOLTAGE IN VOLTS | 24.0 |
| FUSE TERMINAL TYPE ACCOMMODATED | PIN |
| TERMINAL TYPE AND QUANTITY | 2 TAB, SOLDER LUG |
| CONTACT MATERIAL | BRASS |
| CONTACT SURFACE TREATMENT | ANY ACCEPTABLE |
| BODY STYLE | D18 PANEL MOUNTED TYPE |
| OVERALL LENGTH | 1.024 INCHES NOMINAL |
| OVERALL DIAMETER | 0.687 INCHES NOMINAL |
| LENGTH FROM FRONT PROTRUSION TO MOUNTING SURFACE | 0.562 INCHES NOMINAL |
| BUSHING THREAD LENGTH | 0.375 INCHES NOMINAL |
| MOUNTING HOLE STYLE | F17 BUSHING MOUNTING |
| BUSHING HOLE DIAMETER | 0.635 INCHES MINIMUM AND 0.645 INCHES MAXIMUM |
| BUSHING DIAMETER | 0.625 INCHES NOMINAL |
| ACCOMMODATED FUSE LENGTH | 0.348 INCHES NOMINAL |
| ACCOMMODATED FERRULE DIAMETER | 0.250 INCHES NOMINAL |
| INTERRUPTION INDICATOR METHOD | NEON LAMP |
| INDICATING LAMP VOLTAGE RANGE IN VOLTS | 16.0 TO 32.0 |
| ENVIRONMENTAL PROTECTION | DRIPPROOF |
| III TERMINAL MATERIAL | BRASS |
| III BODY MATERIAL | PLASTIC |
Restrictions/Controls & Freight Information | NSN 5920-00-913-2897
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5920-00-913-2897
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9N | Navy-owned stocks of defense electronic material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9E | Defense Supply Center Columbus Columbus, OH 43218 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
