NSN 5925-00-826-1628 MS16555626, MS16555-626 , MS16555630

Product Details | CIRCUIT BREAKER

5925-00-826-1628 A device with means other than fuses for automatically opening the circuit in which it is installed when the current varies from the predetermined value for which the device is set. May include provisions for manual operation. At least one set of contacts must be in series with the actuating element(s). A combination of semiconductor and passive devices may be used in lieu of contacts. For automatically operated items in which the actuating (tripping) element and contacts are not in series, see RELAY (as modified). For items which are operated both manually and automatically but the actuating elements and contact are not in series, see RELAY-SWITCH. Excludes CIRCUIT BREAKER BOX and magneto "breaker" assemblies. See also SWITCH (as modified); and CONTROLLER.

Part Alternates: MS16555626, MS16555-626 , MS16555630, MS16555-630 , A03959 , CD37521, CD3-752-1, CD3C31003, CD3C3-100-3, CD3Z521, CD3-Z52-1, 104A901893 , 128C568H01, 5925-00-826-1628, 00-826-1628, 5925008261628, 008261628

Electrical and Electronic Equipment Components | Circuit Breakers

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	23 AUG 1967	00-826-1628	00136 ( CIRCUIT BREAKER )

Drawings & Photos | NSN 5925-00-826-1628

Part Number	Request Date	QTY	Origin
MS16555626	2025-10-279	2	US
MS16555626	2023-10-303	180	Korea
MS16555626	2023-03-79	170	Korea
MS16555-626	2019-08-232	1300	South Korea
MS16555626	2019-01-11	1	FR
MS16555626	2018-08-214	700	United States
MS16555626	2018-08-214	1400	United States
MS16555626	2017-02-32	110	Australia
MS16555626	2017-01-16	88	Australia
MS16555626	2017-01-11	400	United States
5925-00-826-1628	2016-08-229	47	DIBBS
MS16555626	2016-07-189	1000	United States
MS16555626	2016-07-189	2000	United States
MS16555626	2016-04-118	500	US
MS16555626	2016-04-118	1000	US
MS16555626	2016-04-118	2500	US
MS16555626	2016-04-118	5000	US
MS16555626	2016-04-112	1800	United States
MS16555630	2015-03-86	22	United States
MS16555626	2014-12-342	200	Australia
5925-00-826-1628	2014-06-154	32	DIBBS
MS16555630	2013-12-353	20	US
MS16555630	2013-12-353	30	US
MS16555630	2013-12-353	50	US
MS16555630	2013-12-353	100	US
MS16555626	2013-06-156	20	Australia
MS16555630	2013-04-113	1600	United States
MS16555626	2013-02-38	1000	US
MS16555626	2013-02-38	2000	US
MS16555630	2012-11-326	30	China
MS16555630	2012-08-236	20	United States
MS16555626	2012-07-193	100	US
MS16555626	2012-07-193	500	US
MS16555626	2012-07-193	800	US
MS16555626	2010-03-67	2000	India
5925-00-826-1628	2010-02-36	13	DIBBS
5925-00-826-1628	2009-12-363	5	DIBBS
MS16555626	2009-12-342	8	US
5925-00-826-1628	2009-12-338	8	DIBBS
5925-00-826-1628	2009-10-302	6	DIBBS
5925-00-826-1628	2009-07-183	9	DIBBS
5925-00-826-1628	2009-05-121	4	DIBBS
MS16555630	2008-08-227	70	United States
MS16555630	2008-01-09	2	Australia
MS16555630	2008-01-09	50	Australia
5925-00-826-1628	2007-03-89	21	DIBBS

Cross Reference | NSN 5925-00-826-1628

Part Number	Cage Code	Manufacturer
128C568H01	97942	NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN SYSTEMS
CD3-752-1	74193	EATON CORP HEINEMANN PRODUCTS
CD3-Z52-1	1W134	EATON CORP AEROSPACE COMMERCIAL CONTROLS DIV
CD3-Z52-1	74193	EATON CORP HEINEMANN PRODUCTS
CD3-Z52-1	L3330	HEINEMANN ELECTRIC CANADA INCDIVISION OF EATON CORP
CD3-Z52-1W	1W134	EATON CORP AEROSPACE COMMERCIAL CONTROLS DIV
CD3-Z52-1W	L3330	HEINEMANN ELECTRIC CANADA INCDIVISION OF EATON CORP
CD3C3-100-3	74193	EATON CORP HEINEMANN PRODUCTS

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5925-00-826-1628

Compare

Related Products | NSN 5925-00-826-1628

5925-00-826-1966, 5925-00-826-3002, 5925-00-826-5332, 5925-00-826-5563, 5925-00-826-5656

Technical Data | NSN 5925-00-826-1628

Characteristic	Specifications
POLE QUANTITY	3
MAXIMUM CONTINUOUS LOAD CURRENT RATING PER POLE	100.0 AMPERES AC ALL LOCATIONS
OPERATING VOLTAGE TYPE AND RATING PER POLE IN VOLTS	240.0 AC ALL LOCATIONS
FREQUENCY IN HERTZ	400.0 ALL LOCATIONS
MAXIMUM INTERRUPTING CAPACITY CURRENT TYPE AND RATING PER POLE IN AMPS	5000.0 AC ALL LOCATIONS
CIRCUIT PROTECTION TYPE	OVERCURRENT ALL LOCATIONS
TRIP RELEASE METHOD	MAGNETIC-HYDRAULIC ALL LOCATIONS
INTERNAL TRIP RELEASE CONFIGURATION	SERIES TRIP ALL LOCATIONS
TRIP RELEASE CHARACTERISTIC	TIME DELAY ALL LOCATIONS
TRIP DELAY TIME IN SECONDS PER RATED CONTINUOUS CURRENT	0.350 MINIMUM AT 200 PCT AND 1.500 MAXIMUM AT 200 PCT SINGLE LOCATION
ULTIMATE TRIP RATING OF CONTINUOUS CURRENT RATING PER POLE IN PERCENT	140.0 ALL LOCATIONS
RESET METHOD	MANUAL
MAIN CONTACT TRIPPING MECHANISM TYPE	TRIP FREE
BODY STYLE	8C MULTIPOLE-MULTIPLE ACTUATOR TYPE
BODY LENGTH	5.844 INCHES NOMINAL
BODY WIDTH	3.093 INCHES NOMINAL
CENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO LENGTH	3.546 INCHES NOMINAL
CENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO WIDTH	1.032 INCHES NOMINAL
DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY LENGTH	2.750 INCHES NOMINAL
DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY WIDTH	1.032 INCHES NOMINAL
BOSS HEIGHT	0.218 INCHES NOMINAL
MOUNTING SURFACE TO TERMINAL END DISTANCE	2.609 INCHES NOMINAL
CASE MATERIAL	PLASTIC
MOUNTING FACILITY TYPE AND QUANTITY	6 THREADED HOLE AND 6 SLOT
THREAD SERIES DESIGNATOR	UNC
NOMINAL THREAD SIZE	0.138 INCHES
THREAD QUANTITY PER INCH	32
MOUNTING SLOT WIDTH	0.164 INCHES NOMINAL
MANUAL ACTUATOR TYPE AND QUANTITY	3 TOGGLE
ACTUATOR FUNCTION	TRIP-RESET
ACTUATOR POSITION DESIGNATION	AT EACH POLE
EXTERNAL ACTUATOR LINKAGE ARRANGEMENT	ONE, TWO, AND THREE LINKED
TERMINAL TYPE AND QUANTITY	6 THREADED STUD
INCLOSURE PROTECTION TYPE FOR WHICH DESIGNED	FUNGUS RESISTANT AND MOISTURE RESISTANT
SPECIAL FEATURES	WEAPON SYSTEM ESSENTIAL
CRITICALITY CODE JUSTIFICATION	FEAT
III ARC QUENCHING METHOD	MAGNETIC BLOWOUT
III STORAGE TYPE	GENERAL PURPOSE WAREHOUSE
III SPECIAL HANDLING FEATURE	MAGNETIC
III FRAGILITY FACTOR	MODERATELY RUGGED
