NSN 5935-00-240-3117 A2155, A53656B, SMC5386821
Product Details | PLUG-IN ELECTRONIC COMPONENTS SOCKET
5935-00-240-3117 An item designed to electrically connect and mechanically position the base of an item having plug-in-type contacts, and to facilitate replacement of the item accommodated. It includes sockets which accommodate the contacts of capacitors, coils, crystals, electron tubes, relays, semiconductor devices and vibrators. Excludes sockets or receptacles designed to accommodate plug-in component circuit boards (printed circuit boards) and electronic modules or sub-assemblies. Also excludes heat-dissipating (not heat-sinks) sockets for mounting "power transistors".
Part Alternates: A2155, A53656B, SMC5386821, SMC538682-1, 8486857, 8495157, 85104, 85-104, 8AB, 9905, 1011200039, 101-12-00-039, 1011210044, 101-12-10-044, 12000727, 1200-0727, 150010, 150-010, 152014, 3822, 38-22, 53656, 54B7, 5935-00-240-3117, 00-240-3117, 5935002403117, 002403117
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-240-3117 | 28914 ( SOCKET, PLUG-IN ELECTRONIC COMPONENTS ) |
Drawings & Photos | NSN 5935-00-240-3117
Demand History | NSN 5935-00-240-3117
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 3822 | 2021-04-111 | 2 | US |
| 152014 | 2016-06-173 | 1 | US |
Cross Reference | NSN 5935-00-240-3117
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 101-12-00-039 | 71785 | CINCH CONNECTORS, INC. |
| 101-12-10-044 | 71785 | CINCH CONNECTORS, INC. |
| 1200-0727 | 1MY97 | AGILENT TECHNOLOGIES, INC. DIV AGILENT TECHNOLOGIES |
| 1200-0727 | 28480 | HEWLETT-PACKARD COMPANY DBA HEWLETT-PACKARD CO. OR HP |
| 150-010 | 92739 | AMPEX SYSTEMS CORP |
| 152014 | 12436 | BAE SYSTEMS NATIONAL SECURITY SOLUTIONS INC. |
| 38-22 | 1MY97 | AGILENT TECHNOLOGIES, INC. DIV AGILENT TECHNOLOGIES |
| 38-22 | 28480 | HEWLETT-PACKARD COMPANY DBA HEWLETT-PACKARD CO. OR HP |
| 53656 | 12436 | BAE SYSTEMS NATIONAL SECURITY SOLUTIONS INC. |
| 54B7 | 28108 | BELL AUDIO SYSTEMS INC |
| 8486857 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 8495157 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 8495157 | 19204 | ARMY UNITED STATES DEPARTMENT OF THE |
| 85-104 | 45890 | HARSCO CORPORATION DBA PATTERSON-KELLEY DIVISION |
| 8AB | 71785 | CINCH CONNECTORS, INC. |
| 9905 | 71785 | CINCH CONNECTORS, INC. |
| A2155 | 81535 | AERONAUTICAL COMMUNICATIONS EQUIPMENT INC |
| A53656B | 35351 | GE AVIATION SYSTEMS LLC |
| SMC538682-1 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
