Product Details | PLUG-IN ELECTRONIC COMPONENTS SOCKET
5935-00-928-3825 An item designed to electrically connect and mechanically position the base of an item having plug-in-type contacts, and to facilitate replacement of the item accommodated. It includes sockets which accommodate the contacts of capacitors, coils, crystals, electron tubes, relays, semiconductor devices and vibrators. Excludes sockets or receptacles designed to accommodate plug-in component circuit boards (printed circuit boards) and electronic modules or sub-assemblies. Also excludes heat-dissipating (not heat-sinks) sockets for mounting "power transistors".
Part Alternates: SMC568398, 2135084G3, 300768, 3007-68, 80581G29, 8058-1G29, 5935-00-928-3825, 00-928-3825, 5935009283825, 009283825
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 02 SEP 1966 | 00-928-3825 | 28914 ( SOCKET, PLUG-IN ELECTRONIC COMPONENTS ) |
Drawings & Photos | NSN 5935-00-928-3825
Cross Reference | NSN 5935-00-928-3825
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2135084G3 | 28527 | EXELIS INC. DBA ELECTRONIC SYSTEMS, INTEGRATED |
| 3007-68 | 05869 | RAYTHEON COMPANY DBA RAYTHEON |
| 8058-1G29 | 00779 | TYCO ELECTRONICS CORPORATION |
| 8058-1G29 | 91506 | AUGAT INC |
| SMC568398 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| SMC568398 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
