NSN 5935-01-017-3290 M2726/66-001, M2726/66-001-1, M272666001

Product Details | ELECTRICAL RECEPTACLE CONNECTOR

5935-01-017-3290 An electrical fitting with electrical contacts constructed to be affixed to the end of a cable, conduit, coaxial line, cord, wire (includes printed/etched), PRINTED WIRING BOARD, or the like for convenience in joining with another electrical connector(s) or PRINTED WIRING BOARD. It is designed to be mounted on a bulkhead, chassis, panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER; JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET, PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified) and CABLE ASSEMBLY (as modified). For items with termination wires of more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR.

Part Alternates: M2726/66-001, M2726/66-001-1, M272666001, M2726660011, MA0-02490 ITEM 30, MA0-02490/30, MA00249030, MA002490ITEM30, MIL-R-2726/66 , MILR272666, W-C-596/12, WC596/12-3, WC59612, WC596121, WC596-12-1, WC596123, WC596-12-3, 1142960001, 114-296-0001, 11683162, 1466, 34861049, 5252I, 52621, 5262-1, 5262FP3, 5262GRAY, 5262GRY, 5262-GRY, 5262I, 5320I, 5320-I, 82001, 8200-1, 8200I, 8200-I, 5935-01-017-3290, 01-017-3290, 5935010173290, 010173290

Electrical and Electronic Equipment Components | Connectors, Electrical

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	06 MAR 1976	01-017-3290	15093 ( CONNECTOR, RECEPTACLE, ELECTRICAL )

Drawings & Photos | NSN 5935-01-017-3290

Part Number	Request Date	QTY	Origin
M272666001	2025-02-56	2	United States
5935-01-017-3290	2022-11-315	13	United States
MILR272666	2018-01-11	1	us
82001	2017-12-341	90	US
5935-01-017-3290	2013-07-189	4234	DIBBS
5935-01-017-3290	2012-02-32	2	United States
5935-01-017-3290	2012-02-32	6	United States
5935-01-017-3290	2011-08-238	4	United States
5935-01-017-3290	2011-08-224	4	United States
M272666001	2011-05-128	1	US
M272666001	2010-08-237	1	US
5935-01-017-3290	2008-07-211	725	DIBBS
5935-01-017-3290	2008-06-176	750	DIBBS
5935-01-017-3290	2008-05-149	1135	DIBBS

Cross Reference | NSN 5935-01-017-3290

Part Number	Cage Code	Manufacturer
114-296-0001	95542	NORTHROP GRUMMAN SYSTEMS CORPORATION
11683162	19207	U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM
1466	11419	SIERRA ELECTRIC DIV OF SOLA BASIC INDUSTRIES INC
34861049	40670	MILLER TRAILERS INC
5252I	99059	ENSIGN ELECTRIC HUBBELL INC
5262-1	75582	LEVITON MANUFACTURING CO., INC. DBA LEVITON
5262-GRY	81992	HUBBELL HARVEY INC KELLEMS DIV
5262FP3	74545	HUBBELL INC WIRING DEVICE DIV
5262GRAY	25170	HUBBELL HARVEY INC
5262I	74545	HUBBELL INC WIRING DEVICE DIV
5320-I	75582	LEVITON MANUFACTURING CO., INC. DBA LEVITON
8200-1	74545	HUBBELL INC WIRING DEVICE DIV
8200-I	71183	BRYANT ELECTRIC
M2726/66-001	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
M2726/66-001-1	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MA0-02490 ITEM 30	K2509	ULTRA ELECTRONICS LTD PMES
MA0-02490/30	K2509	ULTRA ELECTRONICS LTD PMES
MIL-R-2726/66	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
W-C-596/12	81348	FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
WC596-12-1	81348	FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
WC596-12-3	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
WC596/12-3	81348	FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5935-01-017-3290

Compare

Related Products | NSN 5935-01-017-3290

5935-01-017-3291, 5935-01-017-3292, 5935-01-017-3293, 5935-01-017-3295, 5935-01-017-3296

Technical Data | NSN 5935-01-017-3290

Characteristic	Specifications
BODY STYLE	9K STRAIGHT SHAPE DUPLEX
OVERALL HEIGHT	1.156 INCHES NOMINAL
OVERALL WIDTH	1.750 INCHES MAXIMUM
BODY LENGTH	2.875 INCHES MAXIMUM
DISTANCE BETWEEN MOUNTING FACILITY CENTERS	3.281 INCHES NOMINAL
COLOR	IVORY
CONNECTOR LOCKING METHOD	FRICTION
POLARIZATION METHOD	CONTACT
MATING END QUANTITY	2
CONTACT POSITION ARRANGEMENT STYLE	ADDS 3,5-15 ALL MATING ENDS
INCLUDED CONTACT QUANTITY	1 1ST MATING END 1ST CONTACT GROUPING 2 1ST MATING END 2ND CONTACT GROUPING 1 2ND MATING END 1ST CONTACT GROUPING 2 2ND MATING END 2ND CONTACT GROUPING
CONTACT REMOVABILITY	NONREMOVABLE ALL MATING ENDS ALL CONTACT GROUPINGS
INCLUDED CONTACT TYPE	D-SOCKET 1ST MATING END 1ST CONTACT GROUPING FLAT SOCKET 1ST MATING END 2ND CONTACT GROUPING D-SOCKET 2ND MATING END 1ST CONTACT GROUPING FLAT SOCKET 2ND MATING END 2ND CONTACT GROUPING
CONTACT MAXIMUM CURRENT RATING IN AMPS	15.0 ALL MATING ENDS ALL CONTACT GROUPINGS
CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS	125.0 ALL MATING ENDS ALL CONTACT GROUPINGS
CONTACT MAXIMUM DC VOLTAGE RATING IN VOLTS	125.0 ALL MATING ENDS ALL CONTACT GROUPINGS
CONTACT MATERIAL	COPPER ALLOY ALL MATING ENDS ALL CONTACT GROUPINGS
TERMINAL TYPE	SCREW ALL MATING ENDS ALL CONTACT GROUPINGS
TERMINAL LOCATION	BACK ALL MATING ENDS ALL CONTACT GROUPINGS
TEST DATA DOCUMENT	81348-W-C-596 SPECIFICATION
SPECIFICATION/STANDARD DATA	81348-W-C-596/12 GOVERNMENT SPECIFICATION
MANUFACTURERS CODE	81348
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	W-C-596/12
MANUFACTURERS CODE	81348
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	WC596/12-3
