NSN 5935-01-076-7544 KA59103, KA-59-103, KA5944

Product Details | ELECTRICAL PLUG CONNECTOR

5935-01-076-7544 An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR.

Part Alternates: KA59103, KA-59-103, KA5944, KA59-44, 82092, 8209-2, 980T1900F, 980-T1900F, 15616, 300855, 30-085-5, 3123671050, 31-2367-1050, 492091A2771, 492091A-27-7-1, 5935-01-076-7544, 01-076-7544, 5935010767544, 010767544

Electrical and Electronic Equipment Components | Connectors, Electrical

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	11 MAY 1979	01-076-7544	01938 ( CONNECTOR, PLUG, ELECTRICAL )

Drawings & Photos | NSN 5935-01-076-7544

Part Number	Request Date	QTY	Origin
5935-01-076-7544	2024-12-339	5	United States
5935-01-076-7544	2024-11-309	15	United States
5935-01-076-7544	2024-11-306	5	United States
5935-01-076-7544	2024-10-303	15	United States
15616	2022-04-102	92	DIBBS
31-2367-1050	2022-04-102	92	DIBBS
492091A-27-7-1	2022-04-102	92	DIBBS
8209-2	2022-04-102	92	DIBBS
980-T1900F	2022-04-102	92	DIBBS
KA-59-103	2022-04-102	92	DIBBS
15616	2021-05-140	678	DIBBS
31-2367-1050	2021-05-140	678	DIBBS
492091A-27-7-1	2021-05-140	678	DIBBS
8209-2	2021-05-140	678	DIBBS
980-T1900F	2021-05-140	678	DIBBS
KA-59-103	2021-05-140	678	DIBBS
15616	2021-05-129	678	DIBBS
31-2367-1050	2021-05-129	678	DIBBS
492091A-27-7-1	2021-05-129	678	DIBBS
8209-2	2021-05-129	678	DIBBS
980-T1900F	2021-05-129	678	DIBBS
KA-59-103	2021-05-129	678	DIBBS
15616	2021-04-110	411	DIBBS
31-2367-1050	2021-04-110	411	DIBBS
492091A-27-7-1	2021-04-110	411	DIBBS
8209-2	2021-04-110	411	DIBBS
980-T1900F	2021-04-110	411	DIBBS
KA-59-103	2021-04-110	411	DIBBS
15616	2021-03-73	411	DIBBS
31-2367-1050	2021-03-73	411	DIBBS
492091A-27-7-1	2021-03-73	411	DIBBS
8209-2	2021-03-73	411	DIBBS
980-T1900F	2021-03-73	411	DIBBS
KA-59-103	2021-03-73	411	DIBBS
5935-01-076-7544	2013-09-268	1185	DIBBS
5935-01-076-7544	2013-06-156	835	DIBBS
30-085-5	2012-11-306	1	China
KA59103	2012-04-118	20	PK
KA-59-103	2012-04-118	20	PK
KA-59-103	2012-04-115	20	PK
30-085-5	2012-04-110	4	PK
980-T1900F	2012-04-110	1	PK
KA-59-103	2012-04-110	10	PK
5935-01-076-7544	2012-02-48	50	CN
30-085-5	2012-02-33	48	US
980-T1900F	2012-02-33	12	US
5935-01-076-7544	2011-10-292	80	PK
5935-01-076-7544	2011-10-292	20	PK
5935-01-076-7544	2007-07-192	1032	DIBBS

Cross Reference | NSN 5935-01-076-7544

Part Number	Cage Code	Manufacturer
15616	71468	ITT CORPORATION DBA I T T CANNON
30-085-5	97499	BELL HELICOPTER TEXTRON INC.
31-2367-1050	74868	AMPHENOL CORPORATION
492091A-27-7-1	66702	COAXIAL COMPONENTS CORP.
8209-2	60674	MICROWAVE DEVICES INC
980-T1900F	94375	AUTOMATIC CONNECTOR
KA-59-103	91836	WINCHESTER ELECTRONICS CORPORATION DBA KINGS ELECTRONICS
KA59-44	91836	WINCHESTER ELECTRONICS CORPORATION DBA KINGS ELECTRONICS
