NSN 5935-01-366-5396 MS3476W82S, MS3476W8-2S, AE776W82S
Product Details | ELECTRICAL RECEPTACLE CONNECTOR
5935-01-366-5396 An electrical fitting with electrical contacts constructed to be affixed to the end of a cable, conduit, coaxial line, cord, wire (includes printed/etched), PRINTED WIRING BOARD, or the like for convenience in joining with another electrical connector(s) or PRINTED WIRING BOARD. It is designed to be mounted on a bulkhead, chassis, panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER; JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET, PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified) and CABLE ASSEMBLY (as modified). For items with termination wires of more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR.
Part Alternates: MS3476W82S, MS3476W8-2S, AE776W82S, AE776W8-2S, MILC26482, MIL-C-26482, 5935-01-366-5396, 01-366-5396, 5935013665396, 013665396
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 28 OCT 1992 | 01-366-5396 | 15093 ( CONNECTOR, RECEPTACLE, ELECTRICAL ) |
Drawings & Photos | NSN 5935-01-366-5396
Demand History | NSN 5935-01-366-5396
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AE776W8-2S | 2024-08-214 | 162 | DIBBS |
| 5935-01-366-5396 | 2017-02-33 | 209 | DIBBS |
| 5935-01-366-5396 | 2014-08-217 | 100 | United States |
| 5935-01-366-5396 | 2013-09-258 | 121 | DIBBS |
| 5935-01-366-5396 | 2012-11-334 | 87 | DIBBS |
| MS3476W82S | 2012-08-230 | 15 | United States |
| 5935-01-366-5396 | 2011-12-342 | 29 | DIBBS |
| 5935-01-366-5396 | 2011-04-91 | 23 | DIBBS |
| 5935-01-366-5396 | 2011-03-62 | 4 | United States |
| MS3476W82S | 2011-03-62 | 4 | United States |
| MILC26482 | 2011-01-27 | 4 | Portugal |
| 5935-01-366-5396 | 2010-11-314 | 6 | DIBBS |
| 5935-01-366-5396 | 2010-10-294 | 9 | DIBBS |
| 5935-01-366-5396 | 2007-06-169 | 18 | DIBBS |
| 5935-01-366-5396 | 2007-02-42 | 32 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5935-01-366-5396
Technical Data | NSN 5935-01-366-5396
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 1.230 INCHES MAXIMUM |
| OVERALL DIAMETER | 1.043 INCHES NOMINAL |
| SHELL TYPE | SOLID |
| SHELL MATERIAL | IRON ALLOY |
| CONTACT POSITION ARRANGEMENT STYLE | ACEZ 8-2 SINGLE MATING END |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-C-26482 |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS3476W8-2S |
Restrictions/Controls & Freight Information | NSN 5935-01-366-5396
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061680 | ELEC WIRING PLUGS ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | ZG | Germany ZH ZJ |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5935-01-366-5396
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
