Product Details | ELECTRICAL CONNECTOR ASSEMBLY
5935-01-469-8026 Two or more CONNECTOR, PLUG, ELECTRICAL; CONNECTOR, RECEPTACLE, ELECTRICAL; ADAPTER, CONNECTOR; JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG, TIP; DUMMY CONNECTOR, PLUG; or DUMMY CONNECTOR, RECEPTACLE in any combination, having a common mounting or mounted on each other, each one capable of being independently replaced. It may be interconnected by means of wire or solder bridgings. For items furnished as mated pairs or sets, see CONNECTOR SET, ELECTRICAL. Excludes DUMMY CONNECTOR SET, ELECTRICAL; JACK ASSEMBLY, TELEPHONE; JACK ASSEMBLY, TIP; PLUG ASSEMBLY, TIP; and CABLE ASSEMBLY (as modified).
Part Alternates: HS60181, HS6018-1, PCI3290181, PCI-329-0181, 5935-01-469-8026, 01-469-8026, 5935014698026, 014698026
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 24 NOV 1999 | 01-469-8026 | 22400 ( CONNECTOR ASSEMBLY, ELECTRICAL ) |
Drawings & Photos | NSN 5935-01-469-8026
Demand History | NSN 5935-01-469-8026
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5935-01-469-8026 | 2020-09-14 | 1 | US |
| PCI-329-0181 | 2020-03-12 | 57 | DIBBS |
| 5935-01-469-8026 | 2019-07-03 | 1 | US |
| 5935-01-469-8026 | 2019-02-25 | 31 | US |
| 5935-01-469-8026 | 2018-06-10 | 141 | DIBBS |
| 5935-01-469-8026 | 2018-02-08 | 10 | US |
| 5935-01-469-8026 | 2017-09-27 | 6 | United States |
| 5935-01-469-8026 | 2017-08-03 | 126 | DIBBS |
| 5935-01-469-8026 | 2017-01-04 | 123 | DIBBS |
| 5935-01-469-8026 | 2016-09-12 | 112 | DIBBS |
| 5935-01-469-8026 | 2015-08-18 | 130 | US |
| 5935-01-469-8026 | 2015-07-17 | 1 | US |
| 5935-01-469-8026 | 2015-07-14 | 107 | DIBBS |
| 5935-01-469-8026 | 2015-06-03 | 116 | DIBBS |
| 5935-01-469-8026 | 2015-03-26 | 106 | DIBBS |
| 5935-01-469-8026 | 2014-10-15 | 35 | DIBBS |
| HS60181 | 2014-06-26 | 1 | United States |
| PCI3290181 | 2014-05-15 | 4 | United States |
| PCI3290181 | 2014-05-15 | 100 | United States |
| PCI3290181 | 2014-05-15 | 200 | United States |
| PCI3290181 | 2014-05-15 | 250 | United States |
| HS60181 | 2014-01-29 | 4 | United States |
| 5935-01-469-8026 | 2011-09-28 | 54 | DIBBS |
| 5935-01-469-8026 | 2011-07-30 | 64 | DIBBS |
| 5935-01-469-8026 | 2011-02-22 | 35 | DIBBS |
| 5935-01-469-8026 | 2011-01-14 | 26 | DIBBS |
| HS60181 | 2010-12-20 | 151 | US |
| 5935-01-469-8026 | 2009-12-23 | 137 | DIBBS |
| 5935-01-469-8026 | 2009-12-07 | 189 | DIBBS |
| 5935-01-469-8026 | 2009-11-19 | 120 | DIBBS |
| 5935-01-469-8026 | 2009-10-30 | 100 | DIBBS |
| 5935-01-469-8026 | 2009-10-30 | 151 | DIBBS |
| HS60181 | 2009-09-30 | 3 | United States |
| 5935-01-469-8026 | 2009-09-30 | 30 | DIBBS |
| 5935-01-469-8026 | 2009-09-25 | 13 | DIBBS |
| 5935-01-469-8026 | 2009-08-04 | 23 | DIBBS |
| 5935-01-469-8026 | 2009-07-22 | 19 | DIBBS |
| 5935-01-469-8026 | 2009-04-16 | 22 | DIBBS |
| 5935-01-469-8026 | 2008-01-16 | 52 | DIBBS |
| 5935-01-469-8026 | 2007-09-05 | 27 | DIBBS |
| 5935-01-469-8026 | 2007-07-10 | 41 | DIBBS |
| 5935-01-469-8026 | 2007-06-07 | 44 | DIBBS |
| 5935-01-469-8026 | 2007-05-06 | 32 | DIBBS |
| 5935-01-469-8026 | 2007-02-22 | 37 | DIBBS |
| 5935-01-469-8026 | 2006-06-08 | 27 | DIBBS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5935-01-469-8026
Related Products | NSN 5935-01-469-8026
5935-01-469-8037, 5935-01-469-8131, 5935-01-469-8191, 5935-01-469-8204, 5935-01-469-8252
Technical Data | NSN 5935-01-469-8026
| Characteristic | Specifications |
|---|---|
| COMPONENT QUANTITY | 9 |
| COMPONENT NAME | CONNECTOR, ELECTRICAL, PLUG, SIX-PIN AUDIO, EMI/RFI, U-229 TYPE |
| MOUNTING METHOD | PLUG-IN |
| MOUNTING CONFIGURATION | 6 PINS, 5 CIRCLING A CENTERED 6TH |
| OVERALL LENGTH | 2.350 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.831 INCHES NOMINAL |
| SPECIAL FEATURES | HAS SOLDER CUP TERMINALS THAT HAVE A FINISH OF GOLD OVER NICKEL |
| III USAGE DESIGN | AUDIO CONNECTOR |
| III END ITEM IDENTIFICATION | 1520-01-135-8250 |
| III PRECIOUS MATERIAL | GOLD |
| III PRECIOUS MATERIAL AND LOCATION | TERMINAL FINISH GOLD |
