NSN 5935-01-485-4207 M24308/26-1, M24308261, 74520M013103
Product Details | ELECTRICAL CONNECTOR JACKSCREW
5935-01-485-4207 A locking device specifically designed to secure engaged electrical connectors. Its mating end is either internally or externally threaded. It is designed to be installed in an ADAPTER (2), CONNECTOR; CONNECTOR BODY, PLUG, ELECTRICAL; CONNECTOR BODY, RECEPTACLE, ELECTRICAL; CONNECTOR, PLUG, ELECTRICAL; CONNECTOR, RECEPTACLE, ELECTRICAL; COVER, ELECTRICAL CONNECTOR; DUMMY CONNECTOR, PLUG; DUMMY CONNECTOR, RECEPTACLE; INSERT, ELECTRICAL CONNECTOR; SHELL, ELECTRICAL CONNECTOR; or a SHIELD, ELECTRICAL CONNECTOR. It may be used for polarization. It may be equipped with a knob, slotted head, knurled head, or the like.
Part Alternates: M24308/26-1, M24308261, 74520M013103, 5935-01-485-4207, 01-485-4207, 5935014854207, 014854207
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 24 MAY 2001 | 01-485-4207 | 36340 ( JACKSCREW, ELECTRICAL CONNECTOR ) |
Drawings & Photos | NSN 5935-01-485-4207
Demand History | NSN 5935-01-485-4207
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| M24308261 | 2024-03-61 | 10 | United States |
| M24308261 | 2023-11-313 | 350 | United States |
| 5935-01-485-4207 | 2020-09-259 | 10 | United States |
| M24308261 | 2020-01-08 | 3 | United States |
| M24308261 | 2015-05-142 | 50 | United States |
| M24308/26-1 | 2014-06-176 | 50 | |
| M24308261 | 2010-11-326 | 3 | United States |
| M24308261 | 2010-07-204 | 2 | United States |
| M24308261 | 2008-12-366 | 1 | United States |
Cross Reference | NSN 5935-01-485-4207
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| M24308/26-1 | 14304 | HARRIS CORPORATION DBA HARRIS RF COMMUNICATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5935-01-485-4207
Technical Data | NSN 5935-01-485-4207
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | 15M THREADED STUD MOUNTED |
| OVERALL LENGTH | 0.562 INCHES NOMINAL |
| OVERALL DIAMETER | 0.187 INCHES NOMINAL |
| MATERIAL | STEEL |
| SURFACE TREATMENT | CADMIUM AND CHROMATE |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 THREADED STUD |
| THREAD SERIES DESIGNATOR | UNC |
| NOMINAL THREAD SIZE | 0.112 INCHES |
| THREAD CLASS | 2A |
| THREAD QUANTITY PER INCH | 40 |
| THREAD DIRECTION | RIGHT-HAND |
Restrictions/Controls & Freight Information | NSN 5935-01-485-4207
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
