NSN 5940-00-229-1082 25170400, 2517-04-00, 7245429013
Product Details | LUG TERMINAL
5940-00-229-1082 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: 25170400, 2517-04-00, 7245429013, 724-542-9013, 5940-00-229-1082, 00-229-1082, 5940002291082, 002291082
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 00-229-1082 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-229-1082
Demand History | NSN 5940-00-229-1082
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5940-00-229-1082 | 2019-09-270 | 120 | CA |
Cross Reference | NSN 5940-00-229-1082
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2417-04-00 | 78189 | ITW SHAKEPROOF AUTOMOTIVE PRODUCTS |
| 2517-04-00 | 78189 | ITW SHAKEPROOF AUTOMOTIVE PRODUCTS |
| 724-542-9013 | 70210 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 724-542-9013 | 99193 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 8215845 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5940-00-229-1082
Technical Data | NSN 5940-00-229-1082
| Characteristic | Specifications |
|---|---|
| BASIC SHAPE STYLE | A21 SOLDER |
| OVERALL LENGTH | 0.438 INCHES |
| OVERALL WIDTH | 0.312 INCHES |
| MATERIAL THICKNESS | 0.025 INCHES |
| CONDUCTOR ACCOMMODATION TYPE | SLANT LUG W/ONE HOLE SINGLE END |
| LARGEST WIDTH | 0.156 INCHES SINGLE END |
| MAXIMUM CONDUCTOR SIZE ACCOMMODATED | 13 AWG |
| MOUNTING METHOD STYLE | D14 RING |
| MOUNTING HOLE DIAMETER | 0.120 INCHES |
| MOUNTING TONGUE WIDTH | 0.312 INCHES |
| MOUNTING FACILITY THICKNESS | 0.025 INCHES |
| ELECTRICAL INSULATION FEATURE | UNINSULATED |
| MATERIAL | COPPER ALLOY CONDUCTOR ACCOMMODATION COPPER ALLOY MOUNTING FACILITY |
| SURFACE TREATMENT | SOLDER CONDUCTOR ACCOMMODATION SINGLE LAYER SOLDER MOUNTING FACILITY SINGLE LAYER |
Restrictions/Controls & Freight Information | NSN 5940-00-229-1082
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
