NSN 5940-00-229-7506 BACT12E10, C32810R90, C328-10R90
Product Details | LUG TERMINAL
5940-00-229-7506 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: BACT12E10, C32810R90, C328-10R90, LA208192, LA20819-2, YAV10R, 20819, 84374182, 8437418-2, 5940-00-229-7506, 00-229-7506, 5940002297506, 002297506
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-229-7506 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-229-7506
Demand History | NSN 5940-00-229-7506
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| BACT12E10 | 2014-01-23 | 192 | United States |
| 5940-00-229-7506 | 2013-04-119 | 922 | DIBBS |
| 5940-00-229-7506 | 2013-04-111 | 922 | DIBBS |
| 5940-00-229-7506 | 2013-04-98 | 922 | DIBBS |
| 5940-00-229-7506 | 2013-03-84 | 922 | DIBBS |
| 5940-00-229-7506 | 2012-08-215 | 100 | United Kingdom |
| 5940-00-229-7506 | 2009-06-174 | 631 | DIBBS |
Cross Reference | NSN 5940-00-229-7506
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 20819 | 28916 | ATLANTIC MICROWAVE CORPORATION DIV COBHAM ELECTRONIC SYSTEMS |
| 20819 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| 20819 | 80006 | LITTON SYSTEMS INC AIRTRON DIV |
| 8437418-2 | 19204 | ARMY UNITED STATES DEPARTMENT OF THE |
| BACT12E10 | 81205 | THE BOEING COMPANY DBA BOEING |
| C328-10R90 | 98410 | MOLEX-ETC INC SUB OF MOLEX INC |
| LA20819-2 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| LA20819-2 | 80006 | LITTON SYSTEMS INC AIRTRON DIV |
| YAV10R | 09922 | SOURIAU USA, INC. |
| YAV10R | 1NJK8 | BURNDY LLC |
