Product Details | ELECTROMAGNETIC RELAY
5945-00-239-7558 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: 2090753711, 209-075-371-1, 83300093, 833-00093, 5945-00-239-7558, 00-239-7558, 5945002397558, 002397558
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 05 NOV 1969 | 00-239-7558 | 32512 ( RELAY, ELECTROMAGNETIC ) |
