NSN 5945-01-057-7430 M39016/39-005M, M3901639005L, M39016-39-005L
Product Details | ELECTROMAGNETIC RELAY
5945-01-057-7430 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: M39016/39-005M, M3901639005L, M39016-39-005L, M3901639005M, MILR3901639, MILR39016-39, 9740082050, 974-0082-050, 10176122-1, 3SAH1605A2, 4575980, 457-5980 , 5945-01-057-7430, 01-057-7430, 5945010577430, 101761221, 010577430
Electrical and Electronic Equipment Components | Relays and Solenoids
