Product Details | ELECTROMAGNETIC RELAY
5945-01-262-4146 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: 29034823, 2903482-3, 800543, 5945-01-262-4146, 01-262-4146, 5945012624146, 012624146
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 28 AUG 1987 | 01-262-4146 | 32512 ( RELAY, ELECTROMAGNETIC ) |
Drawings & Photos | NSN 5945-01-262-4146
Demand History | NSN 5945-01-262-4146
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 012624146 | 2024-08-232 | 1 | United States |
| 5945-01-262-4146 | 2023-07-202 | 1 | United States |
| 5945-01-262-4146 | 2022-06-159 | 1 | United States |
| 5945-01-262-4146 | 2021-09-258 | 1 | United States |
| 5945-01-262-4146 | 2021-01-12 | 1 | United States |
| 800543 | 2018-11-321 | 4 | |
| 5945-01-262-4146 | 2018-11-320 | 4 | NECO |
