Product Details | ELECTRICAL SOLENOID
5945-01-509-5542 An item consisting of one or more coils surrounding an iron core. The coil(s) and the core are moveable in relation to each other. The axial or rotary movement is a result of the magnetic flux of the coil. It is designed to convert electrical energy into mechanical energy. It does not include switch contacts. See also RELAY, ELECTROMAGNETIC, and ELECTROMAGNETIC ACTUATOR.
Part Alternates: M0011C, M001-1C, 5945-01-509-5542, 01-509-5542, 5945015095542, 015095542
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 JUN 2003 | 01-509-5542 | 00310 ( SOLENOID, ELECTRICAL ) |
