NSN 5950-00-799-4163 H80132036, H80132-036, JH485
Product Details | AUDIO FREQUENCY TRANSFORMER
5950-00-799-4163 A transformer which is designed so that part or all of its range of operating frequencies is 20 kilohertz (kilocycles) and below. The maximum value may extend into the radio frequency range. It is generally used in the input, output, amplifier, or oscillator stages of audio and sonar devices.
Part Alternates: H80132036, H80132-036, JH485, PICOA1440, PICO-A-1440, D0T36, D0-T36, DH226, 1783709-36, 130, 1636, 1856464-39, 247ASC1526, 247AS-C1526, 5149301, 51493-01, 663282, 6770300320, 677-0300-320, 677-1485-00, 6771485000, 677-1485-000, 72284922, 722849-22, 5950-00-799-4163, 00-799-4163, 5950007994163, 007994163, 178370936, 677148500, 185646439
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-799-4163 | 00780 ( TRANSFORMER, AUDIO FREQUENCY ) |
Drawings & Photos | NSN 5950-00-799-4163
Demand History | NSN 5950-00-799-4163
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5950-00-799-4163 | 2024-11-331 | 1 | United States |
| 1636 | 2020-09-246 | 6 | ID |
| 178370936 | 2014-03-84 | 1 | Japan |
| 130 | 2012-02-39 | 2343 | IL |
| 677-1485-00 | 2010-11-333 | 10 | |
| 6771485000 | 2009-12-344 | 1 | United States |
Cross Reference | NSN 5950-00-799-4163
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 130 | 31669 | PICO ELECTRONICS, INC. |
| 1636 | 31669 | PICO ELECTRONICS, INC. |
| 1783709-36 | 07187 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 1783709-36 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 1856464-39 | 55972 | HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS |
| 247AS-C1526 | 30003 | NAVAL AIR SYSTEMS COMMAND |
| 51493-01 | 35181 | CAE INC |
| 663282 | F1688 | GOODRICH ACTUATION SYSTEMS BUCVERNON SAS |
| 663282 | F6103 | LUCAS FRANCE SA DIV AEROSPACE FRANCE |
| 677-0300-320 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 677-1485-00 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 677-1485-000 | 95104 | ALCATEL USA INC. DIV WTPG |
| 677-1485-000 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| 722849-22 | 05869 | RAYTHEON COMPANY DBA RAYTHEON |
| D0-T36 | 53342 | OPT INDUSTRIES INC DIV OF ELECTRONIKA INC |
| D0-T36 | 80223 | UNITED TRANSFORMER CORP SUB OF OPT INDUSTRIES INC |
| DH226 | 53342 | OPT INDUSTRIES INC DIV OF ELECTRONIKA INC |
| DH226 | 80223 | UNITED TRANSFORMER CORP SUB OF OPT INDUSTRIES INC |
| H80132-036 | 19133 | MCDONNELL DOUGLAS CORP MCDONNELL DOUGLAS AEROSPACE |
| H80132-036 | 76301 | BOEING COMPANY, THE DBA BOEING |
| JH485 | 15634 | MAGNETIKA, INC |
| JH485 | 80223 | UNITED TRANSFORMER CORP SUB OF OPT INDUSTRIES INC |
| PICO-A-1440 | 31669 | PICO ELECTRONICS, INC. |
