Product Details | AUDIO FREQUENCY TRANSFORMER
5950-01-182-2518 A transformer which is designed so that part or all of its range of operating frequencies is 20 kilohertz (kilocycles) and below. The maximum value may extend into the radio frequency range. It is generally used in the input, output, amplifier, or oscillator stages of audio and sonar devices.
Part Alternates: C88395, C8839-5, X1297, X-1297, X12971, X-1297-1, 92325, 9-232-5, 93055, 9-305-5, 5950-01-182-2518, 01-182-2518, 5950011822518, 011822518
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 22 JUN 1984 | 01-182-2518 | 00780 ( TRANSFORMER, AUDIO FREQUENCY ) |
Drawings & Photos | NSN 5950-01-182-2518
