Product Details | CURRENT TRANSFORMER
5950-01-251-2427 An item consisting of one or more windings, designed to be placed near or connected in series with an alternating current power line to measure the current passing through the line by means of a meter; or to control the current passing through the line by means of a control device. Excludes TRANSFORMER, POWER, CURRENT REGULATING.
Part Alternates: M-118, ITP13526, ITP-1352-6 , M118, 63292301, 632923-01, 100044, 41404, 5950-01-251-2427, 01-251-2427, 5950012512427, 012512427
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 MAR 1987 | 01-251-2427 | 00738 ( TRANSFORMER, CURRENT ) |
Drawings & Photos | NSN 5950-01-251-2427
Demand History | NSN 5950-01-251-2427
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 41404 | 2020-10-20 | 3 | DIBBS |
| ITP-1352-6 | 2020-10-20 | 3 | DIBBS |
| M-118 | 2020-10-20 | 3 | DIBBS |
| 41404 | 2019-06-18 | 2 | DIBBS |
| ITP-1352-6 | 2019-06-18 | 2 | DIBBS |
| M-118 | 2019-06-18 | 2 | DIBBS |
| 41404 | 2019-05-16 | 2 | DIBBS |
| ITP-1352-6 | 2019-05-16 | 2 | DIBBS |
| M-118 | 2019-05-16 | 2 | DIBBS |
| 41404 | 2019-04-30 | 1 | DIBBS |
| ITP-1352-6 | 2019-04-30 | 1 | DIBBS |
| M-118 | 2019-04-30 | 1 | DIBBS |
| 41404 | 2019-02-10 | 1 | DIBBS |
| ITP-1352-6 | 2019-02-10 | 1 | DIBBS |
| M-118 | 2019-02-10 | 1 | DIBBS |
| 5950-01-251-2427 | 2018-06-25 | 1 | DIBBS |
| 5950-01-251-2427 | 2018-06-12 | 1 | DIBBS |
| 5950-01-251-2427 | 2016-03-21 | 1 | DIBBS |
| 5950-01-251-2427 | 2016-03-08 | 1 | DIBBS |
Cross Reference | NSN 5950-01-251-2427
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 100044 | 09349 | MAGNETIC CIRCUIT ELEMENTS, INC DBA M C E |
| 41404 | 03550 | VANGUARD ELECTRONICS COMPANY |
| 632923-01 | 07690 | BAE SYSTEMS CONTROLS INC |
| 632923-01 | 09969 | VISHAY DALE ELECTRONICS, INC. |
| 632923-01 | 89954 | BAE SYSTEMS CONTROLS INC. |
| ITP-1352-6 | 09969 | VISHAY DALE ELECTRONICS, INC. |
| M-118 | 09798 | PAYNE MAGNETICS, INC. |
