NSN 5955-00-978-0445 BG61AH5, 00-978-0445, 009780445
Product Details | QUARTZ CRYSTAL UNIT
5955-00-978-0445 An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL.
Part Alternates: BG61AH5, 5955-00-978-0445, 00-978-0445, 5955009780445, 009780445
Electrical and Electronic Equipment Components | Oscillators and Piezoelectric Crystals
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-978-0445 | 00196 ( CRYSTAL UNIT, QUARTZ ) |
Drawings & Photos | NSN 5955-00-978-0445
Cross Reference | NSN 5955-00-978-0445
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| BG61AH5 | 71034 | BLILEY TECHNOLOGIES INCORPORATED |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5955-00-978-0445
Related Products | NSN 5955-00-978-0445
Technical Data | NSN 5955-00-978-0445
| Characteristic | Specifications |
|---|---|
| MODE OF OSCILLATION | FIFTH OVERTONE |
| CIRCUIT RESONANCE | SERIES RESONANCE |
| SPECIFIED FREQUENCY | 5.000 MEGAHERTZ |
| FREQUENCY TOLERANCE FOR OPERATING TEMP IN PERCENT | -0.0001 TO 0.0001 |
| OPERATING TEMP RANGE | 45.0 TO 90.0 DEG CELSIUS |
| EQUIVALENT RESISTANCE VALUE IN OHMS | 140.0 MAXIMUM |
| DRIVE LEVEL RATING | 70.0 MICROAMPERES NOMINAL |
| STYLE DESIGNATOR | 31 TUBE TYPE, 4 WIRE LEADS |
| OVERALL LENGTH | 0.800 INCHES NOMINAL |
| TERMINAL LENGTH | 1.500 INCHES NOMINAL |
| DIAMETER | 0.790 INCHES NOMINAL |
| HOLDER COVER MATERIAL | GLASS |
| SPECIAL FEATURES | ITEM HAS THREE WIRE LEADS |
Restrictions/Controls & Freight Information | NSN 5955-00-978-0445
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5955-00-978-0445
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9N | Navy-owned stocks of defense electronic material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9E | Defense Supply Center Columbus Columbus, OH 43218 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
