NSN 5961-00-437-6697 S59208, S59-208, JAN2N3569
Product Details | TRANSISTOR
5961-00-437-6697 An active semiconductor device with three or more electrodes. May or may not include mounting hardware and/or heatsink. Excludes SEMICONDUCTOR DEVICE, DIODE and SEMICONDUCTOR DEVICE, THYRISTOR. For solid state devices which are responsive to visible or infrared radiant energy, see SEMICONDUCTOR DEVICE, PHOTO.
Part Alternates: S59208, S59-208, JAN2N3569, RELEASE4850, 62903569, 62-903-569, 644020, 1190092, 119-0092, 15235691, 15-23569-1, 2N3569, 2N3569A, 3520629030, 352-0629-030, 4803414300, 4803-4143-00, 4803416900, 4803-4169-00, 5961-00-437-6697, 00-437-6697, 5961004376697, 004376697
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 SEP 1969 | 00-437-6697 | 20588 ( TRANSISTOR ) |
Drawings & Photos | NSN 5961-00-437-6697
Demand History | NSN 5961-00-437-6697
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2N3569 | 2020-12-338 | 20 | Saudi Arabia |
Cross Reference | NSN 5961-00-437-6697
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 119-0092 | 85604 | KEPCO, INC. |
| 15-23569-1 | 52727 | EMERGENCY BEACON CORP |
| 2N3569 | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| 2N3569 | 02763 | GRIPPE MACHINING AND MANUFACTURING COMPANY |
| 2N3569 | 04713 | FREESCALE SEMICONDUCTOR, INC. |
| 2N3569 | 07263 | FAIRCHILD SEMICONDUCTOR CORP |
| 2N3569 | 12040 | NATIONAL SEMICONDUCTOR CORP |
| 2N3569 | 13715 | FAIRCHILD SEMICONDUCTOR CORP COMPONENTS GROUP |
| 2N3569 | 15818 | TELCOM SEMICONDUCTOR INC |
| 2N3569 | 27622 | BURNS AND TOWNE INC |
| 2N3569 | 30043 | SOLID STATE DEVICES, INC. |
| 2N3569 | 31338 | SEMITRONICS CORP |
| 2N3569 | 34428 | UNITED PAGE INC |
| 2N3569 | 80131 | ELECTRONIC INDUSTRIES ASSOCIATION |
| 2N3569 | C7191 | ADELCO ELEKTRONIK GMBH |
| 2N3569A | C7191 | ADELCO ELEKTRONIK GMBH |
| 352-0629-030 | 13499 | ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS |
| 4803-4143-00 | 14010 | ANADEX INC |
| 4803-4169-00 | 14010 | ANADEX INC |
| 62-903-569 | 99313 | COMMUNICATIONS & POWER INDUSTRIES LLC |
| 62-903-569 | C5845 | CPI INTERNATIONAL INCCOMMUNICATIONS & POWER INDUSTRIES |
| 644020 | 11146 | AMERICAN MONARCH CORP |
| JAN2N3569 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| RELEASE4850 | 80131 | ELECTRONIC INDUSTRIES ASSOCIATION |
| S59-208 | 54418 | MILTOPE CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5961-00-437-6697
Related Products | NSN 5961-00-437-6697
Technical Data | NSN 5961-00-437-6697
| Characteristic | Specifications |
|---|---|
| SEMICONDUCTOR MATERIAL | SILICON |
| INTERNAL CONFIGURATION | JUNCTION CONTACT |
| VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 80.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 40.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 5.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN |
| CURRENT RATING PER CHARACTERISTIC | 500.00 MILLIAMPERES MAXIMUM COLLECTOR CURRENT, DC |
| POWER RATING PER CHARACTERISTIC | 300.0 MILLIWATTS MAXIMUM COLLECTOR POWER DISSIPATION |
| MAXIMUM OPERATING TEMP PER MEASUREMENT POINT | 125.0 DEG CELSIUS JUNCTION |
| INCLOSURE MATERIAL | PLASTIC |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 0.500 INCHES MINIMUM |
| TERMINAL CIRCLE DIAMETER | 0.210 INCHES MAXIMUM |
| TERMINAL TYPE AND QUANTITY | 4 UNINSULATED WIRE LEAD |
| OVERALL LENGTH | 0.240 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.325 INCHES MAXIMUM |
| SPECIAL FEATURES | JUNCTION PATTERN ARRANGEMENT: NPN |
| (NON-CORE DATA) SPECIFICATION/STANDARD DATA | 80131-RELEASE4850 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION |
