5961-00-760-3021 A bistable semiconductor device comprising three or more junctions which is normally a nonconductor until the application of a signal to a gate terminal, at which time the device switches to the conductive state. Includes devices capable of being switched back to the nonconductive state upon application of a different signal to the same or another gate terminal. May or may not include mounting hardware and/or heatsink. For solid state devices which are responsive to visible or infrared radiant energy, see SEMICONDUCTOR DEVICE, PHOTO.
Part Alternates: MS20470AD511, MS20470AD5-11 , D5151A, GHN1000330, GHN10003-30 , 1344700002, 134470-0002, 1344702, 134470-2, 5961-00-760-3021, 00-760-3021, 5961007603021, 007603021
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 07 APR 1972 | 00-760-3021 | 33096 ( SEMICONDUCTOR DEVICE, THYRISTOR ) |
Drawings & Photos | NSN 5961-00-760-3021
Demand History | NSN 5961-00-760-3021
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5961-00-760-3021
Related Products | NSN 5961-00-760-3021
5961-00-760-3024, 5961-00-760-3025, 5961-00-760-4120, 5961-00-760-4746, 5961-00-760-4811
Technical Data | NSN 5961-00-760-3021
| Characteristic | Specifications |
|---|---|
| SEMICONDUCTOR MATERIAL | SILICON |
| INTERNAL CONFIGURATION | JUNCTION CONTACT |
| VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 80.0 MAXIMUM BREAKDOWN VOLTAGE, DC |
| POWER RATING PER CHARACTERISTIC | 250.0 MILLIWATTS MAXIMUM TOTAL POWER DISSIPATION |
| INCLOSURE MATERIAL | GLASS |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 1.000 INCHES MINIMUM |
| TERMINAL TYPE AND QUANTITY | 2 INSULATED WIRE LEAD |
| OVERALL LENGTH | 0.150 INCHES MINIMUM AND 0.175 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.065 INCHES MINIMUM AND 0.075 INCHES MAXIMUM |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| SPECIAL FEATURES | JUNCTION PATTERN ARRANGEMENT: PN |
