Product Details | UNITIZED SEMICONDUCTOR DEVICES
5961-00-934-1654 Two or more discrete semiconductor devices such as diode(s) and/or transistor(s), permanently cased, encapsulated, or potted together to form an inseparable unit. Excludes devices having one or more components other than semiconductor devices. The individually distinct devices forming the unit may be internally connected. The unit in itself does not perform a complete specific function and cannot be assigned a more definite item name. It may include or consist of inseparable matched pairs. May or may not include mounting hardware and/or heatsink. For interconnected items arranged in stack(s), see RECTIFIER, SEMICONDUCTOR DEVICE. For items formed on or within a semiconductor material substrate, formed on an insulating substrate or formed on a combination of both of these types, see MICROCIRCUIT (as modified). Excludes NETWORK (as modified); ABSORBER, OVERVOLTAGE; SEMICONDUCTOR DEVICE SET; and SEMICONDUCTOR DEVICE ASSEMBLY. Do not use if more specific name applies.
Part Alternates: B4811, B481-1, 7060869, 7540217G1, B481, 5961-00-934-1654, 00-934-1654, 5961009341654, 009341654
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 24 FEB 1967 | 00-934-1654 | 61962 ( SEMICONDUCTOR DEVICES, UNITIZED ) |
Drawings & Photos | NSN 5961-00-934-1654
Demand History | NSN 5961-00-934-1654
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| B481 | 2020-09-28 | 1000 | United States |
| B481 | 2019-10-07 | 1000 | United States |
| B481 | 2019-10-04 | 1000 | United States |
| B481 | 2019-09-09 | 1000 | United States |
| B481 | 2019-09-09 | 1000 | United States |
| B481 | 2018-10-09 | 2000 | United States |
| B481 | 2018-09-17 | 1000 | United States |
| B481 | 2018-09-17 | 1000 | United States |
| B481 | 2018-09-17 | 10 | United States |
Cross Reference | NSN 5961-00-934-1654
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 7060869 | 99971 | LOCKHEED MARTIN CORP NAVAL ELECTRONICS & SURVEILLANCE |
| 7540217G1 | 99971 | LOCKHEED MARTIN CORP NAVAL ELECTRONICS & SURVEILLANCE |
| B481 | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| B481-1 | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 5961-00-934-1654
5961-00-934-1697, 5961-00-934-2595, 5961-00-934-2616, 5961-00-934-2785, 5961-00-934-2881
Technical Data | NSN 5961-00-934-1654
| Characteristic | Specifications |
|---|---|
| COMPONENT NAME AND QUANTITY | 4 SEMICONDUCTOR DEVICE DIODE |
| SEMICONDUCTOR MATERIAL | SILICON ALL SEMICONDUCTOR DEVICE DIODE |
| MAXIMUM OPERATING TEMP PER MEASUREMENT POINT | 125.0 DEG CELSIUS AMBIENT AIR |
| INCLOSURE MATERIAL | METAL OR PLASTIC |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 1.000 INCHES MINIMUM |
| TERMINAL TYPE AND QUANTITY | 8 UNINSULATED WIRE LEAD |
| OVERALL LENGTH | 0.440 INCHES MAXIMUM |
| OVERALL HEIGHT | 0.150 INCHES MAXIMUM |
| OVERALL WIDTH | 0.350 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5961-00-934-1654
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063025 | SEMICONDUCTORS/DEVICES NOI ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
