Product Details | UNITIZED SEMICONDUCTOR DEVICE RECTIFIER
5961-01-226-2228 Two or more diode semiconductor devices designed to function as a unit in changing alternating current to direct current. The diode devices are internally connected in series, and are permanently cased, encapsulated, potted, or molded together to form an inseparable unit. These units may be designed as either half-wave or full-wave rectifiers and may be mounted to form either single phase or three phase bridges. For interconnected items arranged in stack(s), see RECTIFIER, SEMICONDUCTOR DEVICE. For items fabricated in the form of a monolithic or thin film structure that perform the function of a circuit, see INTEGRATED CIRCUIT (as modified). Excludes SEMICONDUCTOR DEVICES, UNITIZED; SEMICONDUCTOR DEVICE ASSEMBLY; and RECTIFIER NETWORK, UNITIZED.
Part Alternates: SC3BA2, SENB298, SEN-B-298, D38999/46WB35SN, D3899946WB35SN, 655733, 655-733, 8696051, 869605-1, 86960513B150, 5961-01-226-2228, 01-226-2228, 5961012262228, 012262228
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 13 FEB 1986 | 01-226-2228 | 62108 ( RECTIFIER, SEMICONDUCTOR DEVICE, UNITIZED ) |
Drawings & Photos | NSN 5961-01-226-2228
Demand History | NSN 5961-01-226-2228
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| D3899946WB35SN | 2013-11-19 | 1 | United States |
| D3899946WB35SN | 2013-09-10 | 18 | United States |
| D38999/46WB35SN | 2013-04-23 | 3 | United States |
| 5961-01-226-2228 | 2008-04-29 | 49 | DIBBS |
| 5961-01-226-2228 | 2008-03-19 | 22 | DIBBS |
| 5961-01-226-2228 | 2007-10-05 | 10 | DIBBS |
| 5961-01-226-2228 | 2007-05-23 | 40 | DIBBS |
| 5961-01-226-2228 | 2007-05-18 | 14 | DIBBS |
| 5961-01-226-2228 | 2007-03-30 | 40 | DIBBS |
| 5961-01-226-2228 | 2006-03-17 | 26 | DIBBS |
| 5961-01-226-2228 | 2006-03-10 | 20 | DIBBS |
Cross Reference | NSN 5961-01-226-2228
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 655-733 | 12969 | MICRO USPD INC |
| 869605-1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 869605-1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 869605-1 (3B150) | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| D38999/46WB35SN | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| SC3BA2 | 14099 | SEMTECH CORPORATION |
| SC3BA2 | SH879 | SEMTECH CORPUS CHRISTI, S.A. DE C.V. DIV SEMTECH CORPUS CHRISTI |
| SEN-B-298 | 13409 | RSM ELECTRON POWER, INC. DBA SENSITRON SEMICONDUCTOR |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5961-01-226-2228
Related Products | NSN 5961-01-226-2228
5961-01-226-2229, 5961-01-226-2230, 5961-01-226-2469, 5961-01-226-2659, 5961-01-226-3107
Technical Data | NSN 5961-01-226-2228
| Characteristic | Specifications |
|---|---|
| ABSOLUTE MAXIMUM VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 200.0 WORKING PEAK REVERSE VOLTAGE |
| ABSOLUTE MAXIMUM CURRENT RATING PER CHARACTERISTIC | 25.00 AMPERES FORWARD CURRENT, DC |
| OVERALL LENGTH | 2.250 INCHES NOMINAL |
| OVERALL WIDTH | 0.750 INCHES NOMINAL |
| OVERALL HEIGHT | 0.820 INCHES MAXIMUM |
