Product Details | TRANSISTOR
5961-01-505-0236 An active semiconductor device with three or more electrodes. May or may not include mounting hardware and/or heatsink. Excludes SEMICONDUCTOR DEVICE, DIODE and SEMICONDUCTOR DEVICE, THYRISTOR. For solid state devices which are responsive to visible or infrared radiant energy, see SEMICONDUCTOR DEVICE, PHOTO.
Part Alternates: SC59610133, SC5961-0133, SMM20N502, SMM20N50-2, SMM20N505, SMM20N50-5, 947620, 94-7620, 5961-01-505-0236, 01-505-0236, 5961015050236, 015050236
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
