NSN 5962-01-221-1048 XR567M, XR-567M, XR567M/883B
Product Details | LINEAR MICROCIRCUIT
5962-01-221-1048 A microcircuit whose output is a function of the input; that is, the output varies in a predetermined and essentially predictable manner from the input signal.
Part Alternates: XR567M, XR-567M, XR567M/883B, XR567M883B, 7200995107, 72-00995-107, 5962-01-221-1048, 01-221-1048, 5962012211048, 012211048
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 23 NOV 1985 | 01-221-1048 | 31778 ( MICROCIRCUIT, LINEAR ) |
Drawings & Photos | NSN 5962-01-221-1048
Demand History | NSN 5962-01-221-1048
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5962-01-221-1048 | 2022-04-112 | 1 | United States |
| 5962-01-221-1048 | 2022-04-112 | 2 | United States |
| 72-00995-107 | 2022-01-25 | 2 | DIBBS |
| XR-567M | 2022-01-25 | 2 | DIBBS |
