NSN 5962-01-235-9567 MM54HC244J/883B, MM54HC244J883B, SNJ54HC244J
Product Details | DIGITAL MICROCIRCUIT
5962-01-235-9567 A microcircuit specifically designed to generate, modify, or process electrical signals which operate with two distinct or binary states. These states are commonly referred to as on and off, true and false, high and low, or "1" and "0".
Part Alternates: MM54HC244J/883B, MM54HC244J883B, SNJ54HC244J, CD54HC244F/3A , CD54HC244F3A, 890-132-324, 54HC244/BRAJC, 54HC244BRAJC, 64063261, 6406326-1, 7567418002, 7567418-002, 84096, 8409601RA, 8409601RB, 8409601RX, 5962-01-235-9567, 01-235-9567, 5962012359567, 012359567, 890132324
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 09 JUL 1986 | 01-235-9567 | 31779 ( MICROCIRCUIT, DIGITAL ) |
Drawings & Photos | NSN 5962-01-235-9567
Demand History | NSN 5962-01-235-9567
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5962-01-235-9567 | 2024-06-177 | 1 | United States |
| 5962-01-235-9567 | 2024-06-158 | 1 | United States |
| 5962-01-235-9567 | 2023-03-86 | 1 | United States |
| 8409601RX | 2019-02-46 | 500 | Canada |
Cross Reference | NSN 5962-01-235-9567
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 54HC244/BRAJC | 04713 | FREESCALE SEMICONDUCTOR, INC. |
| 6406326-1 | 55974 | HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS |
| 7567418-002 | 13160 | GENERAL DYNAMICS LAND SYSTEMS INC. DBA WOODBRIDGE TECHNICAL CENTER |
| 84096 | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 8409601RA | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 8409601RB | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 8409601RX | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 890-132-324 | 26055 | PARKER-HANNIFIN CORPORATION DBA ELECTRONICS SYSTEMS DIVISION |
| CD54HC244F/3A | 1MY79 | INTERSIL COMMUNICATIONS INC. |
| CD54HC244F/3A | 34371 | INTERSIL CORPORATION |
| MM54HC244J/883B | 27014 | NATIONAL SEMICONDUCTOR CORPORATION |
| SNJ54HC244J | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5962-01-235-9567
Related Products | NSN 5962-01-235-9567
Technical Data | NSN 5962-01-235-9567
| Characteristic | Specifications |
|---|---|
| OUTPUT LOGIC FORM | COMPLEMENTARY-METAL OXIDE-SEMICONDUCTOR LOGIC |
| DESIGN FUNCTION AND QUANTITY | 8 BUFFER |
| INPUT CIRCUIT PATTERN | 10 INPUT |
| VOLTAGE RATING AND TYPE PER CHARACTERISTIC | 7.0 VOLTS MAXIMUM POWER SOURCE |
| OPERATING TEMP RANGE | -55.0 TO 125.0 DEG CELSIUS |
| TERMINAL TYPE AND QUANTITY | 20 PRINTED CIRCUIT |
| TERMINAL SURFACE TREATMENT | SOLDER |
| INCLOSURE CONFIGURATION | DUAL-IN-LINE |
| INCLOSURE MATERIAL | CERAMIC AND GLASS |
| CASE OUTLINE SOURCE AND DESIGNATOR | D-8 MIL-M-38510 |
| BODY LENGTH | 1.060 INCHES MAXIMUM |
| BODY HEIGHT | 0.140 INCHES MAXIMUM |
| BODY WIDTH | 0.220 INCHES MINIMUM AND 0.310 INCHES MAXIMUM |
| MAXIMUM POWER DISSIPATION RATING | 500.0 MILLIWATTS |
| STORAGE TEMP RANGE | -65.0 TO 150.0 DEG CELSIUS |
| FEATURES PROVIDED | MONOLITHIC AND HIGH SPEED AND 3-STATE OUTPUT |
| TEST DATA DOCUMENT | 96906-MIL-STD-883 STANDARD |
| MANUFACTURERS CODE | 67268 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | 84096 |
| MANUFACTURERS CODE | 67268 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | 8409601RA |
