NSN 5962-01-301-8306 HA2-5190/883, HA25190883, EHA2-5190/883B
Product Details | LINEAR MICROCIRCUIT
5962-01-301-8306 A microcircuit whose output is a function of the input; that is, the output varies in a predetermined and essentially predictable manner from the input signal.
Part Alternates: HA2-5190/883, HA25190883, EHA2-5190/883B, EHA25190883B, 058004653002, 058-004653-002, 5962-01-301-8306, 01-301-8306, 5962013018306, 013018306
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 04-JUN-89 | 01-301-8306 | 31778 ( MICROCIRCUIT, LINEAR ) |
Drawings & Photos | NSN 5962-01-301-8306
Demand History | NSN 5962-01-301-8306
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5962-01-301-8306 | 2012-11-325 | 22 | DIBBS |
| 5962-01-301-8306 | 2011-09-259 | 29 | DIBBS |
| 5962-01-301-8306 | 2011-09-244 | 29 | DIBBS |
| 5962-01-301-8306 | 2011-01-11 | 17 | DIBBS |
| 5962-01-301-8306 | 2010-03-64 | 20 | DIBBS |
| 5962-01-301-8306 | 2010-01-28 | 4 | DIBBS |
| 5962-01-301-8306 | 2010-01-24 | 4 | DIBBS |
| 5962-01-301-8306 | 2009-10-278 | 4 | DIBBS |
| 5962-01-301-8306 | 2009-09-271 | 4 | DIBBS |
Cross Reference | NSN 5962-01-301-8306
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 5962-87784 | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 5962-8778401XC | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| 5962-8778401XX | 67268 | DLA LAND AND MARITIME OPNS SUPPORT GROUP |
| HA2-5190/883 | 1MY79 | INTERSIL COMMUNICATIONS INC. |
| HA2-5190/883 | 34371 | INTERSIL CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5962-01-301-8306
Technical Data | NSN 5962-01-301-8306
| Characteristic | Specifications |
|---|---|
| DESIGN FUNCTION AND QUANTITY | 1 AMPLIFIER, OPERATIONAL, LINEAR |
| INPUT CIRCUIT PATTERN | 2 INPUT |
| OPERATING TEMP RANGE | -55.0 TO 125.0 DEG CELSIUS |
| TERMINAL SURFACE TREATMENT | SOLDER OR TIN OR GOLD |
| INCLOSURE CONFIGURATION | CAN |
| INCLOSURE MATERIAL | CERAMIC |
| BODY LENGTH | 0.150 INCHES MINIMUM AND 0.175 INCHES MAXIMUM |
| BODY OUTSIDE DIAMETER | 0.595 INCHES MINIMUM AND 0.605 INCHES MAXIMUM |
| FEATURES PROVIDED | ELECTROSTATIC SENSITIVE AND HIGH SPEED |
| SPECIAL FEATURES | ESD |
| CRITICALITY CODE JUSTIFICATION | FEAT |
| MANUFACTURERS CODE | 26916 |
| MFR SOURCE CONTROLLING REFERENCE | 058-004653-002 |
Restrictions/Controls & Freight Information | NSN 5962-01-301-8306
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | B | ESD sensitivity |
| Precious Metals Indicator Code: | G | Item contains gold |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
