Product Details | PLATE INSULATOR
5970-01-333-1157 An insulator having flat surfaces, with or without holes, whose thickness does not exceed 25 percent of its length or width, whichever is smaller, and whose shape is other than round. Excludes INSULATOR (1), SPACER; INSULATOR (1), WASHER; MOUNTING PAD, ELECTRICAL-ELECTRONIC COMPONENT; PLATE, ELECTRICAL SHIELD; and TERMINAL BOARD.
Part Alternates: 320551, 5970-01-333-1157, 01-333-1157, 5970013331157, 013331157
Electrical and Electronic Equipment Components | Electrical Insulators and Insulating Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 JAN 1991 | 01-333-1157 | 18296 ( INSULATOR, PLATE ) |
Drawings & Photos | NSN 5970-01-333-1157
Cross Reference | NSN 5970-01-333-1157
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 320551 | 79318 | MEGGITT (NORTH HOLLYWOOD), INC. |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 5970-01-333-1157
5970-01-333-1158, 5970-01-333-1159, 5970-01-333-1160, 5970-01-333-1161, 5970-01-333-1162
Technical Data | NSN 5970-01-333-1157
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 1.250 INCHES NOMINAL |
| OVERALL HEIGHT | 0.250 INCHES NOMINAL |
| FIRST HOLE DIAMETER | 0.688 INCHES MINIMUM AND 0.690 INCHES MAXIMUM |
| SECOND HOLE DIAMETER | 0.778 INCHES MINIMUM AND 0.780 INCHES MAXIMUM |
| SPECIAL FEATURES | USED ON AIRCRAFT,B-1B |
