NSN 5985-01-282-7050 MODEL AN215C, MODEL AN215J, MODELAN215C

Product Details | ANTENNA

5985-01-282-7050 An item consisting of a conductor or a system of conductors specifically designed to radiate and/or receive electromagnetic waves in free space. May include beam-forming devices, drive motors, synchros, radome, and associated mechanical structure.

Part Alternates: MODEL AN215C, MODEL AN215J, MODELAN215C, MODELAN215J, AS3644APN232V, 758211, 75821-1, 88027000181, 8802700018-1, 88027000183, 8802700018-3, 300117-500, 510717-500, 5985-01-282-7050, 01-282-7050, 5985012827050, 012827050, 300117500, 510717500

Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	21 JUL 1988	01-282-7050	00749 ( ANTENNA )

Drawings & Photos | NSN 5985-01-282-7050

Part Number	Request Date	QTY	Origin
300117-500	2025-04-100	66	DIBBS
300117-500	2025-04-99	66	DIBBS
300117-500	2025-03-77	18	DIBBS
300117-500	2024-10-291	18	DIBBS
300117-500	2024-10-280	18	DIBBS
300117-500	2024-09-247	114	DIBBS
300117-500	2023-12-348	2	DIBBS
